The Design and Simulation Analysis of Current Amplifier Circuit of Relay Test

Abstract:

This article proposes a practical and reliable design applicable to DC output power amplifier circuit of relay tester. Through theoretical calculation, the author discuss the amplifier circuit can meet the requirement of relay tester to output, and supply the design and simulation analysis of power amplifier circuit, and expatiate the functions of each module of the circuit. The simulation analysis proves that this circuit is a efficient, stable and feasible conversion circuit which can amply energy.

• Periodical: Advanced Materials Research (Volumes 466-467)
• Pages: 966-970
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.466-467.966
• Online since: February 2012
• Authors: Bai Fen Liu, Xian Wu Fang, Yun Chen
• Keywords: Active Filter, Amplifier, Negative Feedback Simulation

References

[1] Gengsheng Wang. JJCO2Hrelay protection tester[J]. Electric power Automation Equipment, 2000(4): 1-2.

[2] Peiqing Cheng. Digital signal prcessing tutorial[M]. Beijing: Tsinghua University Publishing Pr ess, (2007).

[3] Bing Zhao. relay tester Research and implementation of power amplifiers[D]. 2006: 18-20.

[4] Youbei Geng. using SAP15N/P A sound tube amplifiers[J], E-World, 2000(12): 1-2.

[5] Xiujuan Zhang Xinhua Chen. EDA Design&simulation Practice[M]. Beijing: Mechanical Industry Press, (2002).
