Research on Technology of Variable Spindle Speed Noncircular Turning

Abstract:

To improve the stability and precision of noncircular manufacture process, the variable spindle speed turning is applied to noncircular turning process. The variable spindle turning system is designed. The character of variable spindle speed is analyzed. The linear servo unit available for variable speed noncircular turning process is designed. An active disturbance rejection control technique is applied to servo unit. The experiment results show that surface quality and tracking error of variable spindle speed noncircular turning are better than constant speed machining. The linear servo unit is able to track the desired trajectory of cutting tool motion.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 2653-2656
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.2653
• Online since: February 2012
• Authors: Hui Cao, Ning Liang, Na Zhang
• Keywords: Active Disturbance Rejection Control (ADRC), Linear Motor, Noncircular, Tracking Error, Variable Spindle Speed Machining

References

[1] J.Yu, X.Wang, f.Yang, B.Wu: Chinese Journal of Mechanical Engineering Vol.31 (1995), pp.11-16, in Chinese.

[2] T.Insperger, G.Stepan: Journal of Vibration Control Vol.10 (2004), p.1835–1855.

[3] T.C. Tsao, K.C. Pong: North American Manufacture Research Conference Vol.9 (1991), pp.183-190.

[4] J.Han: Systems Science and Mathematical Sciences Vol.4 (1989), p.328–335.

[5] D.Wu, K.Chen, X.Wang: International Journal of Machine Tools and Manufacture Vol.47 (2007), p.2207–2217.

[6] D.M. Alter, T.C. Tsao: Journal of Engineering for Industry Vol.116 (1994), p.298–307.

[7] H.Cao, S.Li: Machine Design and Research Vol.27 (2011), pp.77-79, in Chinese.
