Research of Permanent Magnet Synchronous Motor Speed Control System Based on DSP

Abstract:

For requirements Permanent magnet synchronous motor (PMSM) speeds control, the digital signal processor (DSP) is used for speed control system of PMSM. By using space vector pulse width modulation (SVPWM) algorithm, system performance is improved, and system costs are reduced. In this paper, the principle of SVPWM is analyzed, and its implementation is described. Through the analysis of permanent magnet synchronous motor in a different coordinate system in the mathematical model system solution is presented, software design for system is described. A DSP-based PMSM speed control system is build, the system is analyzed in MATLAB simulation. That proves the feasibility of the system.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 2891-2894
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.2891
• Online since: February 2012
• Authors: Hui Wang, Xue Ren Dong, Xiao Wei Yang, Feng Nan Liu
• Keywords: Digital Signal Processor (DSP), PMSM, Speed Control, SVPWM

References

[1] L.Y.Li: The design of permanent magnet synchronous motor control system based on DSPF2812. Journal of Yangtze University (Nat Sci Edit), Vol.8 No.6, 106-109, (2011)

[2] X.Miao: Realization of Six Phase PMSM Variable Speed System. Electric Drive, Vol.41 No.5, 7-9, (2011)

[3] Y.H. Chen, F.Luo, Y.G.Xu: The Application of PMSM Vector Control in Elevator based on DSP. MICROPROCESSORS, No.3, 105-107, (2010)

[4] Y.Q.Hu, W.C.Yi, Y.B.Hu, Design of PMSM Speed Control System based on DSP. Microcomputer Information, Vol.24 No.5-2, 166-168, (2008)
