Research on Automobile Transmission Comprehensive Performance Test Experiment Equipment

Abstract:

Automobile transmission is a very important part of automobile, and the comprehensive experimental Testing Bed of automobile transmission has realized the comprehensive performance test of four kinds of types’ automobile transmissions. This text has recommended design, operation principle, characteristic and how to realize the system of comprehensive experimental testing Bed of automobile transmission. This testing Bed adopts electromechanical unify principle. It realizes four manual transmission being changed into given and stock automatically. Meanwhile it adopts Labview software as the developing testing Bed, realizing be controlled frequency conversion speed regulator, Step-servo motor, magnetic particle loader, clutch, etc. by computer at the same time. This testing Bed also measures torque, rotational speed in real-time on input axle and output axle of the transmission.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 3002-3005
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.3002
• Online since: February 2012
• Authors: Feng Li Qiao
• Keywords: Experimental Testing Bed, Performance Test, Transmission

References

[1] Zhang Guangbin, FangKai, Hu Danfeng. The system of the transmission comprehensive performance test platform of the automobile designed and realized. [J]. Electronic Technology 2002 (5).

[2] Yan Qingdong,Feng Yongcun, Yang Wenzheng. The system of the midget car synchronizer controls and the data hands experimental platform. [J]. Journal of War Industry.1997 (3).

[3] Xia Jijin, Fang Kai, Zhang Guangbin, Ang Qinshu. Comprehensive performance test Platform systematic system structure of the transmission and controlling the development of the software. [J]. Automation and Instrument Apparatus. 2003(5)
