Fatigue Life Evaluation on the Seam Welds in the Main Rotation Platform of YTQH800

Abstract:

The fatigue life of the rotation platform of YTQH800 was evaluated based on transient dynamic calculation by using normal stress method in LMS VL. According to the evaluation, fatigue hot spots were predicted. A 3D sub-model with R=1 mm notches was built at one of the hot spots with the highest fatigue damage predicted previously. The stress history is obtained by transient dynamic computation. The detailed fatigue life was obtained by using notch stress method in LMS VL. The results provided technology supports to the structure optimum and improvement.

You might also be interested in these eBooks

Advanced Manufacturing Technology, ICMSE 2012

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 472-475)

Pages:

1577-1581

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.472-475.1577

Citation:

Cite this paper

Online since:

February 2012

Authors:

Ben Xue Liu, Hong Pu Yang, Xin Ke Xiao, Zhen Bo Yang

Keywords:

Main Rotation Platform, Nominal Stress Method, Seam Weld Fatigue, Sub-Model

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] TIAN Shui, WANG Zhao. Explicit nonlinear numerical analysis of dynamical performance of dynamic compaction [J], Rock and Soil Mechanics, 2008, 29(6):1 580-1 584.

Google Scholar

[2] Hasan, Shafiul; Al-Hussein, Mohamed; Hermann, U.H.; Safouhi, Hassan3 .Interactive and dynamic integrated module for mobile cranes supporting system design[J]. Journal of Construction Engineering and Management, 2010，136（2）：179-186.

DOI: 10.1061/(asce)co.1943-7862.0000121

Google Scholar

[3] Vormwald, M., and T. Seeger. Crack Initiation Life Estimations for Notched Specimens with Residual Stresses Based on Local Strains. In: E. Macherauch, V. Hauk, Eds., Residual Stresses in Science and Technology, S. 743-750, DGM Informationsgesellschaft, 1987.

Google Scholar

[4] Hobbacher A. et al.Recommendations for assessment of weld imperfections in respect of fatigue.IIW doc. XIII-1266-88/XV-659-88

Google Scholar

[5] Köttgen V.B., Olivier R., Seeger T.Fatigue analysis of welded connections based on local stressesIIW document XIII-1408-91, (1991)

Google Scholar
