Design of the System for Online Monitoring Dielectric Loss

Abstract:

For knowing the dielectric loss of high-voltage capacitive electrical equipment timely and mastering the electrical insulation of high voltage equipment effectively to ensure the reliable operation of these voltage equipments, an online monitoring system is designed in this paper based on the practical project. The system is made up of two parts including lower computer and upper computer. Using the microcontroller C8051F023 as the core of the lower computer and adopting an improved zero-crossing comparison method, the measurement of dielectric loss is realized and the data are sent to upper computer by wireless way. SQL2000 is used in the upper computer for data management, which can be real-time displayed, inquired and printed in report forms. At present, this monitoring system has successfully applied in the Houqiao 330 kV transformer substation in Ningxia. The operating results show that the system can meet well the online monitoring demand of the high voltage capacitive electrical equipment.

• Periodical: Advanced Materials Research (Volumes 472-475)
• Pages: 1568-1571
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.472-475.1568
• Online since: February 2012
• Authors: Jian Feng Zheng, Hao Qiang
• Keywords: Capacitive Equipment, Dielectric Loss, Online Monitoring

References

[1] W. B. Wand, Z. H. Wu, S. H. Wand: Journal of Xihua University Natural Science, Vol. 24 (2005), pp.60-62

[2] S. John: IEEE Communications Magazine, Vol. 8(1997), pp.97-104

[3] J. F. Zheng, M. X. Wang. Solar-powered MOA-line monitoring instrument, China, Patent 201120220437.8 (2011)

[4] J. F. Zheng, M. X. Wang. Solar-powered wireless Insulation Online Monitoring instrument, China, Patent 201120220438.2 (2011)

[5] H. W. Li, P. Wan: Electrial Measurement & Instrumentation, Vol. 38 (2001), p.27~29

[6] G. Andria, M. Savinu: IEEE. Transactions on Instrumentation and Measurement, Vol. 38 (1999), pp.856-863
