Measurement Data Restoring Method of Shoe Last Based on Numerical Cutting Technology

Abstract:

From the perspective of Analytic Geometry, the spatial equation of milling cutter rotary surface is obtained. According to the measurement and machining of shoe last, a new measurement data restoring technology that is named Numerical Cutting is presented, and the Numerical Blade is defined. The working principle of Numerical Cutting Technology is introduced in detail, and it is used to restore the measurement data of shoe last. Then the discrete model of shoe last is gotten by shoe last CAD software. Finally, an application example of Numerical Cutting Technology is presented.
