The Ball Screw Installation Position Parameter Decisions and Simulation

Abstract:

The robot joints are usually rotational axis by two link joints, bionic features is not strong. The shortcomings of intelligent MR damper control multi-axis bionic knee can only provide resistance and certain sizes of regain momentum, cannot provide larger power, therefore this paper gives by the multi-axis four-bar structure, ball screw transmission hybrid drive multiaxial bionic active knee institutions. And analysis the human leg institutions and commonly used two-bar structure, solve the ball screw transmission installation location parameters. And established based on hybrid drive of the bionic active the knee's virtual prototype.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 2347-2350
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.2347
• Online since: February 2012
• Authors: Ki Jun Kim, Cheng Dong Wu, Fei Wang, Shi Guang Wen
• Keywords: Active Intelligent Knee, Ball Screw, Four-Bar Bionic Knee, Hybrid Drive
