Design and Analysis of Hydraulic-Driven Bionic Joint for Undulating Thruster

Abstract:

Undulate fin is the main propelling organ of MPF mode fish, which could produce propelling wave continually and controllabily while swimming, and this propelling mode has characteristics of high efficiency and low disturbance to fluid field. In this paper, biological structure of “Nilotic Ghost” fish’s long flexible fin(Undulate Fin) is studied with physiological anatomizing and X-ray perspectiving means. Then motion characteristics of the undulate fin are revealed with pictures from fish’s swimming video. Under the bionical conclusions, a hydraulic-driven bionic joint for undulating thruster is designed, including a pair of restoration springs. At last some calculating simulation and testing experiments are carried out, so as to analyze and verify this bionic joint’s characteristics. Results show that, bionic joint driven by hydraulic system could immitate the flexible movements of natural rib in undulate fin, which are described as position restoration, changing of swaying range as well as frequency.

• Periodical: Advanced Materials Research (Volumes 479-481)
• Pages: 2355-2360
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.479-481.2355
• Online since: February 2012
• Authors: Hai Jun Xu, Cun Yun Pan, Dai Bing Zhang, Xiang Zhang
• Keywords: Bionic Joint, Hydraulic Transmission, Ribbing of Fin, Undulate Fin

References

[1] Toda Y., Ikedab H., Sogihara N. The Third International Symposium on Aero Aqua Bio-mechanisms. Okinawa.(2006)

[2] Liu J., Hu H. International Journal of Automation and Computing. Vol.3(4): pp.336-347(2006).

[3] Triantafyllou M. S., Triantafyllou G. S., Yue K. P. Annual Review on Fluid Mechanics. Vol.32: pp.33-35(2000).

[4] Guanrong Hang, Zhenlong Wang, Jian Wei etc. Robot. Vol.30(2): pp.171-176(2008).(In Chinese)

[5] Jinghu Yu, Chang'an Zhu, Gang Chen etc. Robot. Vol.26(5):pp.416-420(2004). (In Chinese)

[6] Haijun Xu, Cunyun Pan, Daibing Zhang, Haibin Xie. Machine Design and Research. Vol.26(1): pp.111-114(2010). (In Chinese)

[7] Bandyopadhyay P. R. IEEE Journal of Oceanic Engineering. Vol.30(1): pp.109-139(2005).

[8] Bandyopadhyay P. R. IEEE Journal of Oceanic Engineering. Vol.29(3): pp.542-546(2004).

[9] Kai Yu, Sheng Huang, Jian Hu etc. Journal of Huazhong University of Science & Technology(Nature Science Edition). Vol.35(11): pp.117-120(2007). (In Chinese)

[10] Lincheng Shen, Guangmin Wang. Journal of National University of Defense Technology. Vol.27(4): pp.96-100(2005). (In Chinese)

[11] Guangmin Wang. Theoretic and Experimental Research on Propulsion by Bionic Undulatory Fin[D]. Changsha: National University of Defense Technology. 2008.(In Chinese)

[12] Guangmin Wang, Tianjiang Hu, Lincheng Shen. Chinese Mechanical Engineering. Vol.13(7): pp.1526-1530(2007). (In Chinese)

[13] Yiqun Wang, Wei Zhang. Chinese Journal of Mechanical Engineering. Vol.39(10): pp.95-99(2003). (In Chinese)

[14] Fish F. E., Lauder G. V. Annual Reviews on Fluid Mechanics. Vol.38: pp.193-224(2006).
