Design of Self-Adaptive ZVS Protection Circuit for Electronic Ballast

Abstract:

The overlap of the voltage and current of power MOSFET will leads large power loss when power MOSFET in a ballast turns on. To solve this problem, a self-adaptive ZVS protection circuit is proposed, which consists of a dead time control circuit and a ZVS control circuit. Compared with traditional circuit with fixed dead time, it can regulate the dead-time automatically to realize ZVS with a negative feedback loop and result reduction advantages come from, such as the induction of power loss and EMI, meanwhile the efficiency is improved. Hspice simulation shows that the ZVS protection circuit in the ballast with an input voltage of 14V and an operation frequency of 50 kHz can realize the self-adaptive dead time.

• Periodical: Advanced Materials Research (Volumes 482-484)
• Pages: 1235-1240
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.482-484.1235
• Online since: February 2012
• Authors: Xian Rui Li, Qian Liu, Rui Shen
• Keywords: Ballast, Dead Time, EMI, Half Bridge Inverter, Zero Voltage Switching (ZVS)

References

[1] Moo Chin Sien, Lee Kuo Hsing, Cheng Hung Liang et al. A single-stage high-power-factor electronic ballast with ZVS buck-boost conversion[J]. IEEE Transactions on Industrial Electronics, 2009, 56(4): 1136-1146.

DOI: 10.1109/tie.2008.2008338

[2] Orletti R, Co M A, Simonetti D S L, et al. HID lamp electronic ballast with reduced component number[J]. IEEE Transactions on Industrial Electronics, 2009, 56(3): 718-725.

DOI: 10.1109/tie.2008.2011599

[3] Liu Jianmin1, Kai Pingan. A new control method with applications for dead time systems[C]// Chinese Control and Decision Conference, 2010: 1097-1101.

DOI: 10.1109/ccdc.2010.5498138

[4] Seon-Hwan Hwang, Jang-Mok Kim. Dead time compensation method for voltage-fed PWM inverter. IEEE Transactions on Energy Conversion, 2010, 25(1): 1-10.

DOI: 10.1109/tec.2009.2031811

[5] Jong Tae Hwang, Dae Ho Kim, Moon Sang Jung, et al. Intelligent high-voltage high-power ballast IC[C]// 7th Internatonal Conference on Power Electronics. Daegu: IEEE, 2008: 53-58.

DOI: 10.1109/icpe.2007.4692347

[6] B R Lin, C L Huang, M Y Li. Novel interleaved ZVS converter with ripple current cancellation[J]. International Journal of Circuit Theory and Applications, 2008, 37(3): 413-431.

DOI: 10.1002/cta.480

[7] Lee Sung Sae, Moon Gun Woo. High-efficiency boost half-bridge converter with fast boost current transferring ZVS operation[J]. IEEE Transactions on Power Electronics, 2008, 23(4): 1822-1829.

DOI: 10.1109/tpel.2008.924625

[8] Chiang Chu Yi, Chen Chern Lin. Zero-voltage-switching control for a PWM buck converter under DCM/CCM bounda[J]. IEEE Transactions on Power Electronics, 2009, 24(9): 2120-2126.

DOI: 10.1109/tpel.2009.2021186

[9] Ben Yaakov Sam, Shvartsas Moshe, Ivensky Gregory. HF multiresonant electronic ballast for fluorescent lamps with constant filament preheat voltage[J]. IEEE Transactions on Industry Applications, 2008, 44(1): 61-67.

DOI: 10.1109/tia.2007.912740
