Accurate Calculation and Control of Dry Dual-Clutch Torque during Shifting Process

Abstract:

Aiming at the work and structural characteristic of dual clutch transmission (DCT), the control of clutch torque is analyzed during shifting process; A system dynamic model has been established; Several key influence factors of clutch transmit torque are raised, and then the accurate formula for each factor is derived respectively; Model and simulation are made up by MATLAB /SIMULINK, and then the clutch torque is analyzed during shifting process for a DCT car. The results indicate that the jerk will be reduced effectively by coordinated control for the changing ratio of clutch torque during shifting process.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 1913-1919
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.1913
• Online since: March 2012
• Authors: Zhen Jun Liu, Lei Wang, Chuan Bing Ren
• Keywords: Dry Dual Clutch, Shifting Process, Simulation Analysis, Torque Transmission

References

[1] Jianjun Hu, Guanghui Li, Guoqiang Wu, et al: Automotive Engineering Vol30 (2008), pp.1083-1086, in Chinese.

[2] Yuting Li, Zhiguo Zhao, Tong Zhang: China Mechanical Engineering Vol21 (2010), pp.1496-1501, in Chinese.

[3] Datong Qin, Yuxing Zhao, et al: Journal of Chongqing University Vol32 (2009), pp.1016-1023, in Chinese.

[4] Aanshi Xu, Fahcao Jiang. Vehicle Clutch (TSINGHUA University Press, Beijing2005), pp.48-49, in Chinese.

[5] Shizhu Wen, Ping Huang. Tribological Principle (TSINGHUA University Press, Beijing2002), pp.384-387, in Chinese.

[6] Jinle Zhang, BIiao Ma, et al: Transactions of the Chinese Society of Agricultural Machinery. Vol41 (2010), pp.6-11, in Chinese.

[7] Toshimichi Minowa, Tatsuya Ochi and Hiroshi Kuroiwa: SAE, 1999-01.

[8] Wei Chen, Pengcheng Gui, et al: Journal of HEFEI University of Technology Vol32 (2009), pp.171-174, in Chinese.

[9] Zhenjun Liu, Xiaohong Dong, et al: Journal of Chongqing University Vol33 (2010), pp.29-34, in Chinese.
