Research on Dynamic Characteristic of the Rotors Connected by the Misaligned Gear Coupling

Abstract:

The misalignment of gear coupling is the most commonly observed fault in industry fields. It can cause great harm. In order to find out its physical mechanism and dynamic charactersic, a new Finite Element Modal of misaligned rotor-bearing system with gear coupling is presented in this paper. By considering the forces and moments which applied on rotor in two typical misaligned conditions, i.e. parallel and angular misalignment, the dynamic equation is established. Through simulation and dynamic analysis of two-span rotor system with misalignment, quantitive relationship between the misalignment and steady-state response is obtained. Meanwhile, an investigation on phase of twice rotational speed freqency (2X) reveals that in parallel misaligned condition, the phases of two sides of coupling are same, while in angular misalignment condition the phases are opposite (almost 180°difference). This feature can be used as an important reference when confirming a misalignment fault.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 2662-2666
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.2662
• Online since: March 2012
• Authors: Wen Ping Lei, Jie Han, Ling Jun Li, Lei Chen
• Keywords: Dynamic Characteristic, Finite Element, Gear Coupling, Misalignment, Phase Characteristic

References

[1] HAN Jie, SHI LaiDe. Study on kinematic mechanism of misalignment fault of rotor system connected by gear coupling: Journal of Vibration Engineering, Vol. 17-4 (2004), p.416.

[2] HAN Jie, SHI LaiDe: Fullvector spectrum and its application in Engineering (China Machine Press, China 2008).

[3] HE ChengBing, GU YuJiong, YANG Kun. Properties analysis on coupled lateral and torsional vibrations of the rotor connected by the gear coupling: Journal of MechanicalStrength. Vol. 27-6(2005), p.725.

[4] Tejas H. Patel, Ashish K. Darpe. Vibration response of misaligned rotors: Journal of Sound and Vibration, Vol. 325(2009), p.609.

DOI: 10.1016/j.jsv.2009.03.024

[5] Sekhar A. S, Prabhu B.S. Effects of coupling misalignment on vibrations of rotating Machinery: Journal of Sound and Vibration, Vol. 185-4(1995), p.655.

DOI: 10.1006/jsvi.1995.0407

[6] Arun Kr. Jalan, Mohanty A.R. Modal based fault diagnosis of a rotor-bearing system for misalignment and unbalance under steady-state condition: Journal of Sound and Vibration, Vol. 327(2009), p.604.

DOI: 10.1016/j.jsv.2009.07.014

[7] Muszynska A. Misalignment and shaft crack-related phase relationships for 1X and 2Xvibration components of rotor responses: Orbit, Vol. 10-2(1989), p.4.
