Virtual Prototype Simulation of Fine-Adjustment System Kinematics for Segment Erector of Tunnel Boring Machine

Abstract:

In this paper, we present the modeling and kinematics simulation of fine-adjustment system for segment erector of tunnel boring machine (TBM), which is performed in the virtual prototype platform. The 3D virtual assembling model of fine-adjustment system is built with Pro/E software according to its design parameters such as structure and size. After the interference inspection, the model is imported into ADAMS through the interface module of Mech/Pro. The model is simplified and optimized reasonably and various constraints are applied under variety working conditions. The results of simulation show that the design has three degrees of freedom movement capacity which meets the design requirements. At the same time the kinematics characteristics of each part along three different directions are obtained and they will provide some references for the further optimal design.

• Periodical: Advanced Materials Research (Volumes 490-495)
• Pages: 3883-3886
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.490-495.3883
• Online since: March 2012
• Authors: Gang Li, Ya Dong Chen, Bo Wang, Wan Shan Wang
• Keywords: Fine-Adjustment System, Kinematic Simulation, Segment Erector, Tunnel Boring Machine, Virtual Prototype

References

[1] Martin David: Tunnelling and Underground Space Technology, Vol. 22 (1990), pp.54-55.

[2] Weyrich M, Drews P: the virtual workbench, Vol. 38 (2006), pp.5-15.

[3] J.J. Cao and N.M. Qi: Journal of Mechanical Design and Manufacturing Vol. 1 (2006), p.11.

[4] W. He, G.X. Peng and Y.P. Hu: Journal of Mechanical Engineering Vol. 11 (2000), p.33.

[5] MSC. Software Corporation: Using MSC. ADAMS Function Builder (MSC, USA 2007).
