Size Effects on Transferability and Mold Change of Glass Molding Press for Microgrooves

Abstract:

Glass molding press (GMP) was applied to the fabrication of 3 kinds of microgrooves with different pitches on the glass surface. The size effects of microgroove fabrication on the Nickel Phosphorous (Ni-P) plating layer by diamond cutting were experimentally tested, and then, the size effects of microgroove fabrication by GMP using the Ni-P mold were experimentally tested. Finally, the changes of the Ni-P mold after GMP by 100 shots were compared with the microgroove mold before GMP, and the size effects of the mold change were discussed. By the comparison research of microgroove fabrication with different pitches, it suggests a way to create microgrooves with even smaller size.

• Periodical: Advanced Materials Research (Volume 497)
• Pages: 235-239
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.497.235
• Online since: April 2012
• Authors: Tian Feng Zhou, Ji Wang Yan, Tunemoto Kuriyagawa
• Keywords: Glass Molding Press, Micro Cutting, Micro-Forming, Microgrooves, Size Effect

References

[1] Yan, J., Oowada, T., Zhou, T., Kuriyagawa, T., Precision machining of microstructures on electroless-plated NiP surface for molding glass components. Journal of Materials Processing Technology. 2009, 209(10): pp.4802-4808.

DOI: 10.1016/j.jmatprotec.2008.12.008

[2] Moriya, T., Nakamoto, K., Ishida, T., Takeuchi, Y., Creation of V-shaped microgrooves with flat-ends by 6-axis control ultraprecision machining. CIRP Annals - Manufacturing Technology. 59(1): pp.61-66.

DOI: 10.1016/j.cirp.2010.03.054

[3] Chao, C.H., Shen, S.C., Wu, J.R., Fabrication of 3-D submicron glass structures by FIB. Journal of Materials Engineering and Performance. 2008, DOI: 10. 1007/s11665-008-9318-1.

[4] Matsumura, T., Hiramatsu, T., Shirakashi, T., Muramatsu, T., A study on cutting force in the milling process of glass. Journal of Manufacturing Processes. 2005, 7(2): pp.102-108.

DOI: 10.1016/s1526-6125(05)70087-6

[5] Zhou, T., Yan, J., Yoshihara, N., Kuriyagawa, T., Masuda, J. Investigation on the Transferability of Precision Molding Process for Aspherical Glass Lenses. In the 8th International Conference on Frontiers of Design and Manufacturing. 2008, Tianjin, China.

[6] Zhou, T., Yan, J., yoshihara, N., Kuriyagawa, T. Shape Compensation of the Molding Dies in Glass Molding Press for Aspherical Lens. In Proceedings of the 9th International Conference on Frontiers of Design and Manufacturing. 2010, Changsha, China.

DOI: 10.1299/jamdsm.4.806

[7] Zhou, T., Yan, J., Masuda, J., Oowada, T., Kuriyagawa, T., Investigation on shape transferability in ultraprecision glass molding press for microgrooves. Precision Engineering. 2011, 35(2): pp.214-220.

DOI: 10.1016/j.precisioneng.2010.09.011

[8] Zhou, T., Yan, J., Masuda, J., Kuriyagawa, T., Investigation on the viscoelasticity of optical glass in ultraprecision lens molding process. Journal of Materials Processing Technology. 2009, 209(9): pp.4484-4489.

DOI: 10.1016/j.jmatprotec.2008.10.030

[9] Li, H., Chen, H., Dong, S., Yang, J., Deng, J.F., Study on the crystallization process of Ni-P amorphous alloy. Applied Surface Science. 1998, 125(1): pp.115-119.

DOI: 10.1016/s0169-4332(97)00379-6
