Testing System Development of Outdoor Fitness Equipment

Abstract:

A testing system for the outdoor fitness equipment has been developed, which conforms to the new national standard. It can be applied to fatigue performance test, stability test and impact deformation test. Using Omron CPM2A PLC, the system guarantees industrial-level reliability. Measurement data is acquired and subsequently transmitted to PC via Host Link protocol. Developed in C#, the monitoring program applies a dedicated measurement thread. Attention has been paid to the assignment of PLC data memory. Therefore improved performance in speed can be achieved.

• Periodical: Advanced Materials Research (Volumes 503-504)
• Pages: 1518-1521
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.503-504.1518
• Online since: April 2012
• Authors: Fan Zhang, Tian Jie Wang
• Keywords: Fatigue Performance Test, Fitness Equipment, Host Link Protocol, Impact Deformation Test, PLC Measurement System, Stability Test

References

[1] SAC, Safety for outdoor body-building equipment -General requirements, GB 19272-(2011).

[2] Omron, CPM1/CPM1A/CPM2A/CPM2C/SRM1(-V2) Programmable Controllers Programming Manual, (2008).

[3] Jeffrey Richter, CLR via C# , third ed, Microsoft Press, Washington, (2010).

[4] Scott W. Ambler, The Elements of UMLTM 2. 0 Style, Cambridge University Press, Cambridge, (2005).
