Study on Implementation Technology of the Hydraulic System of Certain Engineering Equipment

Abstract:

The model suitable to the fault test and diagnosis of hydraulic system of certain engineering equipment is described. The corresponding hardware and software platforms are developed, which can realize data acquisition, processing and fault diagnosis. Based on the multi-thread and multi-panel control technology, the parallel processing and order execution of tasks are achieved. The channel configuration files and system parameter configuration files are made, which can implement automatic signal acquisition. The corresponding remote test and diagnosis system is build based on C/S mode.

• Periodical: Advanced Materials Research (Volumes 503-504)
• Pages: 206-210
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.503-504.206
• Online since: April 2012
• Authors: Xue Xia Liu
• Keywords: Fault Diagnosis, Fault Test, Multi Panel Control, Multithread Panel Control, Remote Test

References

[1] National Instruments Corporation: SC-2345/2350 Carrier User Manual, Austin: National Instrument Company, (2006).

[2] Suochang Yang, Chen Meng and Shaohui Cui: Computer automated measurement&control, Vol. 9 (2001), pp.33-35, in Chinese.

[3] Meijun Zhang, Xiaoqiang Yang: Engineering machinery fault test (PLA University of Science and Technology Press, Nanjing 2000), in Chinese.

[4] Li Chen and Zhenjie Lin: Industrial control technology, Vol. 10 (2006), pp.92-94, in Chinese.
