Design and Application of New Testing Slots in the Tracking Control System

Abstract:

A test soil-bin is an effective device to test the whole or components of the agricultural machinery. A new computer control and test system featuring PLC control and PXI bus has been designed to control the whole soil bin system including motion control and correlative date processing. This paper introduces the software design as well as the hardware design of the electric control system and test system. The result of the present work implied that soil-bin testing platform can provide reliable data for agricultural machinery research, which has a significant effect on the agricultural machinery technology innovation and saving the cost of research and development.

• Periodical: Advanced Materials Research (Volume 507)
• Pages: 112-116
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.507.112
• Online since: April 2012
• Authors: Yan Yu, Xiao Hong Liu, Shu Qi Shang
• Keywords: E2000, Frequency Converter, PTR2000, Remote Controller, Test Soil-Bin

References

[1] Yu Yan, Gong Linong and Shang Shuqi. Development of soil bin test dynamic parameters measurement system. Transactions of the Chinese Society of Agricultural Engineering Vol. 27(13): 323-328.

[2] YU Yan, LIU Xiao-hong, TIAN Li-zhong. Design of Control System for Testing Platform of Soil-bin for Agricultural Machine Based on PLC. Agricultural engineering new technology international academic conferences 2011(EI), 5: 67-69.

DOI: 10.1109/icae.2011.5943750

[3] Yu Yan, Shang Shuqi. Development of Dynamic Remote-measuring System in Soil Bin for Agricultural Machinery on PXI. Journal of Agricultural Mechanization Research. 2011. 33(2): 139-142.

[4] Yu Yan, Shang Shuqi. Design and application of new testing slots in the tracking control system. Journal of Northeast Agricultural University, 2011. 42(2): 69-72.

[5] Yu Yan, Shang Shuqi. Design of Control System for Tests Platform of Soil-bin for Agricultural Machine Based on PLC. Journal of Agricultural Mechanization Research, 2011. 1: 138-140.

DOI: 10.1109/icae.2011.5943750

[6] TIAN bin, WU Jan-min, HU Jing-ming. Design of new trial soil slot for no-tillage farm machinery. Journal of Gansu Agricultural University, 2006. 41(1): 94-96.

[7] Wang Weixing Luo Xi. Research on Computerized Simulation Loading System for Soil Trough Tests. THANSACTIONS OF THE CHINESE SOCIETY OF AGRICULTURAL ENGINEERING, 1997. 13(4): 27-30.
