The Design Analysis of Cold Storage Refrigeration System Heat Recovery Coupled Solar Auxiliary Heated Drying Device

Abstract:

In order to effectively reduce the comprehensive energy consumption of the refrigeration system so as to achieve the purpose of energy saving and emission reduction, from a practical point of view, this design studied cold storage refrigeration system’s exhaust heat recovery device and its applications, which fully recovered the exhaust sensible heat of refrigeration system and combined with solar collector’s work to provide energy for materials drying. Through the design and matching of the solar collectors, exhaust heat recovery unit, dehumidification evaporator, drying chamber assembly structure and controlled atmosphere organization to achieve the device’s technical synthesis of freezing and drying, so as to realize a comprehensive energy consuming system of one input and two outputs, which provides a new direction for the energy-saving development of similar devices.

• Periodical: Advanced Materials Research (Volumes 512-515)
• Pages: 1235-1240
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.512-515.1235
• Online since: May 2012
• Authors: Min Li, Zhi Qiang Guan, Xiao Qiang Jiang
• Keywords: Cold Storage Refrigeration System, Dehumidification Evaporator, Drying Devices, Heat Recovery Heat Exchanger, Solar Collector

References

[1] F. BILLIARD "Refrigeration and sustainable development", "China's refrigeration and air conditioning industry development forum," April 2003.

[2] MortenB.Blarke ,ErikDotzauer, Energy,36(2011):6867~6878

[3] S.S. Elsayeda,T.Miyazaki,Y.Hamamotob,etal. international journal of refrigeration , 31(2008):189~196

[4] Kumar, R.; Khaliq, A. Journal of the Energy Institute,84(2011):192~199

[5] Bhattacharje, Kaushik, Journal of the Association of Energy Engineering ,105(2008):55~63

[6] Min Li ; Zhan Li ; Xiaoqiang Jiang,etal. Design and analysis on energy recovery system of aquatic product comprehensive process factory, ICEET 2009,2009(1):79~84

DOI: 10.1109/iceet.2009.26

[7] Min Li ; Zhan Li ; Xiaoqiang Jiang,etal. Design and performance analysis of the heat pump-based condensing heat of cold storage recovery drying equipment, CDCIEM 2011,2011(2): 158-161

DOI: 10.1109/cdciem.2011.258

[8] Reindl, D.T.; Jekel, T.B. ASHRAE Journal,49(2007.8):22~28

[9] Liu, Meng ; Zhang, Na; Hu, Shun-Feng, Journal of Engineering Thermophysics(in Chinese), 29(2008.1): 5~8.
