Overlaying Weld Cracks of Pinch Roller and its Formation Mechanism

Abstract:

Overlaying pinch roller has higher surface hardness. If the overlaying technology is improper, small circumferential cracks may occur on the welded surface and even peel off. From failure analysis, it is indicated that the contents of C, S, and O were higher around the cracking area in the deposited metal. Optical microscopic observation shows that some cracks grew along the direction of columnar crystals and residual austenite. Due to high content of inclusions and austenite in the deposited material and poor plasticity of the deposited metal, small cracks are easy to be found at the defect such as blue flecks. In addition, a large number of cracks intersect on the deposite surface, resulting in large peeled area.

• Periodical: Advanced Materials Research (Volumes 512-515)
• Pages: 1965-1971
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.512-515.1965
• Online since: May 2012
• Authors: Qing Bao Wang, Zhuo Xin Li, Yao Wu Shi, Guo Dong Li, Hui Wang
• Keywords: Crack, Overlaying, Pinch Roller, Residual Austenite

References

[1] E.N. Gregory.Surfacing by welding[M]. Weld. Res. Bull. (1975) 69-71

[2] Ernest F. Nippes.  Welding,brazing and soldering[M], Metals Handbook, ninth edition, vol.6, American Society for Metals, Metals Park, Ohio, 1983, pp.771-772.

[3] R.S. Chandel,Hardfacing consumables and their characteristics for mining and mineral processing industry[J], Indian Weld. J. (2001) 26-34

DOI: 10.22486/iwj.v34i1.178619

[4] Song Weixi,Metallography[M] Metallurgical Industry Press (Second Edition) 2007.6:97-115 (in Chinese)

[5] C.D. Elcoate R.J. Dennis P.J. Bouchard Three dimensional multi-pass repair weld simulation[C], International Journal of Pressure Vessels and Piping, 82(4), p.244–257I.

DOI: 10.1016/j.ijpvp.2004.08.003

[6] A.R. Ortega, Analysis and validation of multi-pass girth in pipes[C], in: 8th Int. Conf. of Casting, June 779-786, 998, San Diego, USA.

[7] J.Dike, J. Brooks, J. Krafcik, Finite element modeling and verification of thermal–mechanical behavior in the weld pool region[C], in: 4th International Conference on Trends in Welding Research. Gatlinburg, USA, 1995.

[8] Y.H. Wei, Z.B. Dong, Three dimensional numerical simulation of weld solidification cracking[J], Model. Simul. Mater.Sci. 13 (2005) 437-454.

DOI: 10.1088/0965-0393/13/3/012

[9] Chinese Mechanical Engineering Society Welding Society, Welding Handbook -Material Welding [M] Mechanical Industry Press (Second Edition) 2001.7:122-132 (in Chinese)

[10] Zhou Zhenfeng and Zhang Yue, Welding Metallurgy and Metal Weldability [M] Mechanical Industry Press (Second Edition) 1998.11:200-204 (in Chinese)

[11] I.R. Sare, B.K. Arnold, Met. Forum 3 (1) (1980) 47

[12] George Labeas, Ioannis Diamantakos. Numerical investigation of through crack behaviour under welding residual stresses[J] Engineering Fracture Mechanics 76 (2009) 1691-1702

DOI: 10.1016/j.engfracmech.2009.03.006

[13] Overbeke JL, Alting AJ, Jonkers PAM. Influence of weld parameters on fatigue strength under CA and VA loading of welded joints in HSLA steels[J]. IIW Doc. 1991; No. IIW-XIII-1404-91.

[14] Rading GO. Effect of welding on the fatigue crack growth rate in a structural steel[J]. Welding J 1993;71:307s-311s.

[15] Moraitis GA, Labeas GN. Residual stress and distortion calculation of laser beam welding for aluminum lap joints[J]. J Mater Process Technol 2008;198(1-3):260-269.

DOI: 10.1016/j.jmatprotec.2007.07.013

[16] Tan JML, Fitzpatrick ME, Edwards L. Stress intensity factors for through-thickness cracks in a wide plate: derivation and application to arbitrary weld residual stress fields[J]. Engng Fract Mech 2007;74(13):2030–54.

DOI: 10.1016/j.engfracmech.2006.10.017

[17] T. Liang Teng, P.H. Chang, A study of residual stresses in multi-pass girth-butt welded pipes[J], Int. J. Pres. Ves. Piping 74 (1997) 59-70.

DOI: 10.1016/s0308-0161(97)00091-4
