The Influence of Insulation Bushing on Insulation Performance of Vacuum Insulated Tubing Coupling

Abstract:

In the injecting steam wellbore, insulated tubings are connected with couplings. The coupling is short, but its insulation performance is poor. There are two different coupling types: couplings with insulation bushing and couplings without insulation bushing. By combining on-site experiments and fluent simulation, thermal insulation performance of coupling with insulation bushing and without insulation bushing were discussed. The results showed that the apparent heat conductivity of the coupling with insulation bushing is about 0.4W/(m•K), the apparent heat conductivity of the coupling without insulation bushing is about 3.6 W/(m•K). Insulation bushings promote insulation performance of vacuum insulated tubing coupling significantly.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1551-1554
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1551
• Online since: May 2012
• Authors: Hai Qian Zhao, Zhong Hua Wang, Xiao Yan Liu
• Keywords: Bushing, Coupling, Insulated Tubing, Simulation, Thermal Insulation
