Investigation of Output Power and Efficiency of Wound-Rotor Brushless Doubly-Fed Machine

Abstract:

Brushless Doubly-fed Machine (BDFM) is a new type of the induction machine, which has wide application in the fields of variable-speed generator and drive systems. The key factor affecting its performance is the rotor structure. In this paper, taking wound-rotor BDFM for instance, firstly, according to the relationship between the equivalent circuit parameters of the BDFM, the core equivalent circuit model of the BDFM has been derived. Secondly, based on the core equivalent circuit model and the constraints of electromagnetic load, the power distribution between the power and control windings and the constraint condition of maximum output of active power has been obtained. Thirdly, according to the simplified model of the equivalent circuit, the copper loss and the relationship between the output power and efficiency of the machine have been investigated. Finally, the anlysis results are verified by the experimental data.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1604-1609
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1604
• Online since: May 2012
• Authors: Jun Zhang, Xue Fan Wang
• Keywords: Brushless Doubly-Fed Machine (BDFM), Efficiency, Equivalent Circuit, Output Power, Wound Rotor

References

[1] S. Willianson, A. C. Ferreira, A. K. Wallace. Generalised theory of brushless doubly-fed machine. Part 1: Analysis. IEE Proceedings - Electric Power Applications, Vol. 144, No. 2, pp.111-122. (1997)

DOI: 10.1049/ip-epa:19971051

[2] R. A. McMahon, P. C. Roberts, X. Wang, P. J. Tavner. Performance of BDFM as generator and motor. IEE Proceedings - Electric Power Applications, Vol. 153, No. 2, pp.289-299. (2006)

DOI: 10.1049/ip-epa:20050289

[3] P. C. Roberts, R. A. McMahon, P. J. Tavner, J. M. Maciejowski, T. J. Flack, X. Wang. Performance of rotors for the brushless doubly-fed (induction) machine (BDFM). 16th International Conference of Electrical Machines, Cracow, Poland, pp.450-455. (2004)

DOI: 10.1109/icelmach.2010.5607908

[4] L. Xu, F. Liang, T. A. Lipo. Transient Model of a Doubly Excited Reluctance Motor. IEEE Transactions on Energy Conversion, Vol. 6, No. 1, pp.126-133. (1991)

DOI: 10.1109/60.73799

[5] Xuefan Wang. A new brushless doubly-fed machine with a wound-rotor changing-pole winding. Proceedings of the CSEE, Vol. 23, No. 6, pp.108-111. (2003) (in Chinese)

[6] A. R. W. Broadway, L. Burbridge. Self-cascade machine: a low speed motor or high frequency brushless alternator. Proceedings of the Institution of Electrical Engineers, Vol. 117, No. 7, pp.1270-1290. (1970)

DOI: 10.1049/piee.1970.0247

[7] R. Mahaja, A. Saxena, B. S. Khehra. A genetic approach to standard cell placement using various genetic operators. International Journal of Computer Application, Vol. 1, No. 9, pp.85-87. (2010)

DOI: 10.5120/193-332

[8] Roberts P C，McMahon R A，Tavner P J，et al．Equivalent circuit for the brushless doubly fed machine (BDFM) including parameter estimation and experimental verification[J]．IEE Proceedings- Electric Power Applications， 2005， 152(4)： 933-942．

DOI: 10.1049/ip-epa:20045106

[9] Roberts P C, McMahon R A. Performance of BDFM as generator and motor [C]. IEE Proc., Electra. Power Appl., 2006, 153, (2), p.289–299

DOI: 10.1049/ip-epa:20050289
