The Electromagnetic and Thermal Analysis of Permanent Magnet Brushless DC Motor in Cars

Abstract:

As the wide application of DC brushless motor in cars, this paper introduces a kind of motor design method that based on finite element theory. The motor electromagnetic simulation is analyzed by using finite element termed as Ansoft, the simulation results and experimental data are anastomotic, so the method is verified feasible. The motor in cars is restricted to the volume, the motor temperature index influence all basic parameters seriously, in this paper baseing on the motor loss simulate the motor 3D temperature distribution, and find out the highest spot, for designing the cooling system of similar motors provide instructional effect, and this is of important engineering significance.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1660-1663
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1660
• Online since: May 2012
• Authors: Yan Li, Ying Qin, Yong Zhi Liu, Jia Kuan Xia
• Keywords: DC Brushless, Electromagnetism, Finite Element, Thermal

References

[1] Yan Hu, Jianwen Wu, Decheng Li. Modern Practical Design Techniques of Small Motors.Beijing: Chine Machine Press,2008.

[2] Bijiao Sun, Jing He. Torpedo Technology, 2006, 14(4): 7-10.

[3] Guoqiang Liu, Lingzhi Zhao, Jiya Jiang. The Ansoft Software of Engineering Electromagnetic Finite Element Analysis. Beijing: Publishing House of Electronics Industry,2005.

[4] Dong Ye, Fengqi Zhang, Liling Sun. Proceeding of The Csee, 1998, 18(5): 335-340.

[5] Peng Xiao, Wei Wang, Ying Zhang, Wu Ai. Micro-motor, 2009, (11).

[6] Shiming Yang. Heat Transfer. Beijing: Higher Education Press, 2006.
