Design of Intelligent Power Meter for Demand Response of Smart Grid

Abstract:

To support the demand response function for smart grid, an intelligent power meter with hybrid communication module has been proposed in this paper. The circuit module consisting of VI measurement, power calculation chip, microprocessor and PLC/ZigBee/RS-485 communication is designed to support load control to achieve load reduction after receiving the demand response command of via two way communication. The load control function can also be activated by the real time pricing information, which has been downloaded from utility control center. The embedded power management system is developed to perform the management of intelligent power meters to monitor and control electrical appliances. Based on the field test, the intelligent power meter can be used for load shedding or power due to achieve energy conservation and enhance system stability for smart grid application.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 1692-1698
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.1692
• Online since: May 2012
• Authors: Chao Shun Chen, Te Tien Ku, Chia Hung Lin
• Keywords: Demand Response, Intelligent Power Meter

References

[1] Fuller, J.C., Schneider, K.P. and Chassin, D.: Analysis of Residential Demand Response and double-auction markets, IEEE Power and Energy Society General Meeting. (2011)

DOI: 10.1109/pes.2011.6039827

[2] Kumar, J.: Modeling of demand response contracts with operational reliability indices in distribution management system, IEEE Power Systems Conference and Exposition. (2009)

DOI: 10.1109/psce.2009.4840187

[3] Dissanayaka, D.M.L.B., Fernando, C.T.J. and Abeyratne, S.G.: Smart meter based inverter controlling network for demand response applications in smart grids, ICIIS. (2011)

DOI: 10.1109/iciinfs.2011.6038065

[4] Wang, Sitong, Luo, Ranran, Zhou, Hui, Su, Jie and Zhu, Xiaolei: Research on reliability enhancement testing for single-phase smart meter, ICECE. (2011)

[5] Shang-Wen Luan, Jen-Hao Teng, Shun-Yu Chan and Lain-Chyr Hwang: Development of a smart power meter for AMI based on ZigBee communication, PEDS. (2009)

DOI: 10.1109/tencon.2011.6129006

[6] Samarakoon, K., Jianzhong Wu, Ekanayake, J. and Jenkins, N.: Use of delayed smart meter measurements for distribution state estimation, IEEE Power and Energy Society General Meeting. (2011)

DOI: 10.1109/pes.2011.6039384

[7] Ling Zou, Sihong Chu and Biao Guo: The design of prepayment polyphase smart electricity meter system, ICISS. (2010)

DOI: 10.1109/iciss.2010.5656086

[8] Wenshu Zhang and Liuqing Yang: SC-FDMA for uplink smart meter transmission over low voltage power lines, ISPLC. (2011)

DOI: 10.1109/isplc.2011.5764449
