Impact Of Diffuser Width On The Performance Of AP1000 Reactor Coolant Pump

Abstract:

For the problem of incapable to determine the width of spherical diffuser, four groups of spherial diffusers with different width were designed by using the speed coefficient method. Numerical investigation of internal flow in the nuclear coolant pumps with these diffusers was made based on ANSYS-CFX software. Aimed at the efficiency, ditribution of pressure and velocity vector on the meridian plane of each volute scheme was analysised emphatically. By comparing the performance curves of the coolant pumps predicted by the numerical simulation, we can draw that the head and efficiency of pump decreased as the increasing of diffuser width and performanced worst at the width of d=1.7R, then the performance no longer changes when diffuser width continue to reduce.

• Periodical: Advanced Materials Research (Volumes 516-517)
• Pages: 921-925
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.516-517.921
• Online since: May 2012
• Authors: Dan Qing Yuan, Hua Yan, Pei Pei Wang
• Keywords: AP1000 Reactor Coolant Pump, Numerical Simulation, Spherical Diffuser

References

[1] Wu Qin, Zhipeng Li, Zongzhao Shen et al.: Status and development of nuclear reactor coolant pump[J]. Pump Technology, Vol 3 (2007), pp.1-6.(In Chinese)

[2] Yang I J , Teng M Y, HuanW I, et al.: Decontamination of the reactor coolant pump in Maanshan nuclear power plant[ J ]. Nuclear Engineering and Design, Vol. 167 (1996), p.91

DOI: 10.1016/s0029-5493(96)01247-2

[3] Zhijiang Wu,WanYong Zhao: Numerical simulation of interior flow field of mixing flow pump[J].Fluid Machinery, Vol. 33-10 (2005), p.15.(In Chinese)

[4] Peng Zhang.:Numerical simulation of the effect of structure parameters on the mixing circulating water pump performance[J]. Energy Conservation, Vol. 5 (2006), pp.25-27.(In Chinese)

[5] Chunyuan Yuan.: Numerical calculation of turbulent flow and performance experiment of mixed-flow pump impeller[J]. Transactions of the Chinese Society of Agricultural Machinery, Vol. 39-3(2008), pp.52-55.(In Chinese)

[6] Xingfan Guan. Theory and Design of the Pump[M].Mechanical Industry Press (1987).(In Chinese)

[7] Koai K L，soedel W．Gus pulsation in twin screw compressors．Part II：Dynamics of discharge system and its iteration with port now[A]．Pronc Interation compressor Engineering conference [C], purdue (1990), pp.50-59.

[8] Wuke Liang, Yantong Dong, Daoli Zhao et al.: Influences of relief pipes' states on flow field of francis hydralic turbine[J]. Journal of Power Engineering, Vol. 28-4 (2008),pp.600-605. (In Chinese)
