Design of Small-Scale Radial Inflow Turbine Integrated into Organic Rankine Cycle

Abstract:

Organic Rankine Cycle (ORC) is dramatically suitable for low temperature waste-heat generation. The small-scale radial inflow turbine is introduced to integrate into the ORC characterized by simple structure, low parts count, high efficiency, especially getting high efficiency under the condition of smaller flow. This turbine is comprised of four main parts named by the volute, the nozzle (stator), the impeller (rotor), and the diffuser respectively. This paper introduces how to design and model the parts in detail, discusses modeling skills and shares experience. The structure of the volute and impeller is so complicated that parts are not easy to model. These 3D models can directly import to both ANSYS and FLUENT to analysis the flow field in order to achieve the optimize parameters.

• Periodical: Advanced Materials Research (Volumes 524-527)
• Pages: 3907-3913
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.524-527.3907
• Online since: May 2012
• Authors: Hui Wang, Xin Ling Ma, Xin Li Wei
• Keywords: Low-Temperature Waste Heat Generation, Organic Rankine Cycle (ORC), Radial Inflow Turbine Model Design
