Microstructure and Toughening Mechanism of ZrO₂ Ceramic

Abstract:

In order to reduce its costs and increase its strength and toughness, 3Y-ZrO2/Al2O3 nanocomposite ceramics is fabricated through pressureless sintering process. Microstructure is detected by SEM and composition is analyzed by EDS. The results show that some of ZrO2 combined with Al2O3 forms ZrO2+Al2O3 solid solutions, and the others form particles which are distributed on grain boundaries and matrixes with different shapes. Those ZrO2 particles locating in the boundaries enhance the ceramic’s toughness by two modes: fracturing and tearing, and which one to be occur depends on the location relationship between load and boundary interface. The composition transition, i.e. the solid solution consisting of ZrO2+Al2O3 has formed encircling ZrO2 particles, and it has a positive contribution to ceramics toughness through the combination of chemical bond.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 535-537)

Pages:

814-818

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.535-537.814

Citation:

Cite this paper

Online since:

June 2012

Authors:

Chen Wang, Ya Ling Han, Si Cong Guo, Fu Sheng Zhang, Hai Feng Fu

Keywords:

Boundary, Bridging Connection, Distribution of Particles, Inlay Mode, Microstructure, Particles’ Tearing, Toughening, Zirconia

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] I.A. Chou, H.M. Chan, M.P. Harmer: Journal of the American Ceramic Society. Vol. 79 (1996), p.2403–2409.

Google Scholar

[2] L. Gao, W. Li and H.Z. Wang, et al: Journal of Inorganic Materials. Vol. 15 (2000), p.1005–1008. (In Chinese)

Google Scholar

[3] L.L. Shi, L.K. Zeng and H. Wang: Materials Review. Vol. 17 (2003), p.72–74. (In Chinese)

Google Scholar

[4] L. Gao, W. Li: Nanoceramics (Chemical Industry Press, China, 2002)(In Chinese)

Google Scholar

[5] M. Yoshimura, T. Ohji and M. Sando, et al: Journal of Materials Science Letters. Vol. 17 (1998), p.1389–1391.

Google Scholar

[6] S.C. Liao, W.E. Mayo, K.D. Pae: Acta Materialia. Vol. 45 (1997), p.4027–4040.

Google Scholar

[7] A.G. Evans, R.M. Cannon: Acta Metallurgica. Vol. 34 (1986), p.761–800.

Google Scholar

[8] F.F. Lange: Journal of Materials Science. Vol.17 (1982), p.240–246.

Google Scholar

[9] Y.S. Yin, J.Li: Zirconia ceramics and composites (Chemical Industry Press, China, 2004) (In Chinese)

Google Scholar

[10] B. Basu, J. Vleugels and O. Van der Biest: Journal of the European Ceramic Society. Vol. 25 (2005), p.3629–3637.

DOI: 10.1016/j.jeurceramsoc.2004.09.017

Google Scholar
