Effect of Different Nucleating Agents on the Microstructure and Properties of LMAS Glass-Ceramics

Abstract:

Li2O-MgO-Al2O3-SiO2(LMAS) system glass-ceramics had been prepared by sintering method. The effect of different nucleating agents on the phase composition, microstructure and properties of LMAS system glass-ceramics were investigated by DTA, XRD and SEM. The results indicate that the introduction of nucleating agents could contribute to decreasing the crystallization temperature of the glass-ceramics, the effect of the nucleating agent TiO2 is most obvious, and the crystallization temperature is the lowest(798.9°C). Main crystal phase of the glass-ceramics without the nucleating agents is β-quartz solid solution, while main crystal phase of the glass-ceramics with different nucleating agents changes into β-spodumene solid solution. The glass-ceramics with composite nucleating agents (TiO2+ZrO2+P2O5) are the lowest coefficient of thermal expansion (0.86×10-6/°C)and the highest flexural strength (95MPa). Composite nucleating agents have the best effect of crystallization, and contribute to the formation of a large number of short columnar crystals, which is the main reason for obtaining glass-ceramics with low expansion coefficient and high flexural strength.

• Periodical: Advanced Materials Research (Volumes 535-537)
• Pages: 819-823
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.535-537.819
• Online since: June 2012
• Authors: Wei Hui Jiang, Yuan Fa Wu, Jian Min Liu, Qing Xia Zhu, Xun Yan Tan, Zhen Hong Bao, Peng Peng Yu
• Keywords: Glass-Ceramic, Microstructure, Nucleating Agent, Phase Composition, Property Analysis

References

[1] J.S. Cheng: Glass Ceramics ( Chemical Industry Press, China 2006) (In Chinese)

[2] C.S. Ray, D.E. Day: Ceramic Transactions Vol.207(1993), P.207

[3] Y.Zhao, L.Lu and L.J. Zhang: Bulletin of the Chinese Ceramic Society Vol.10(2007),P.1 (InChinese)

[4] J.F.Wu, C.G.Li: Journal of Wuhan University of Technology Vol.13(2009), P.1 (InChinese)

[5] C.L. Zhang, L.Lei: China Ceramics Vol.46(2010), P.26 (InChinese)

[6] A.Marotta, A.buri and F.Branda: Journal of Materials Science Vol.16(1981), P.341

[7] X.Q. Liu, W.Z. Song and J.Y. Wang: Acta Chemica Sinica Vol.65(2007), P1394 (InChinese)

[8] P.Riello, N.Canto and N.Comelato: Journal of Non-Crystalline solids Vol.288(2001), P.127

[9] M.H. Lin and M.C. Wang: Journal of Materials Research Vol.11(1996),P.2611(InChinese)

[10] K.D. Kin, S.H. Lee and HK.Ahn: Journal of Non-crystalline Solids Vol.336(2004), P.195
