Simulation Analysis for Hydraulic Clamping Force of Bidirectional Hydraulic Lock' Valve Spool Based on Fluent

Abstract:

Bidirectional hydraulic lock is a key component of hydraulic system of the truck crane[1]. By using Fluent software, this paper simulates and analyses the hydraulic clamping phenomenon, which happens in the truck crane outrigger bidirectional hydraulic lock's spool in the case of taper exists, as well as the center lines of spool and valve sleeve are eccentric, and the effect of different kinds of pressure-equalizing grooves on hydraulic clamping force, then concludes that the number, the shape and the size of pressure-equalizing grooves, and whether pressure-equalizing grooves are concentric can take effect on clamping force, thus a new way is prompted to improve the structure of bidirectional hydraulic lock.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 1091-1095
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.1091
• Online since: June 2012
• Authors: Qing Liang Zeng, Jing Cui, Wen Ming Zhao
• Keywords: Bidirectional Hydraulic Lock, Clamping Force, Fluent, Pressure-Equalizing Groove

References

[1] Zhichun Xu: Construction Machinery & Maintenance. Vol. 2 (2011), pp.184-185. In Chinese.

[2] Xudong Pan, Guanglin Wang, Zesheng Lu: Energy Conversion and Management. Vol. 52 (2011), pp.3249-3256.

[3] Hongwei Zhang, Congchang Zhan, Liandong Fu: Manufacturing Informatization. Vol. 10 (2009), pp.68-69. In Chinese.

[4] Fujun Wang: Principle and Application of CFD Software. Tsinghua University Press (2004). In Chinese.

[5] Kuisheng Chen, Wenjuan Zhou, Yuan Guo: Machine Tool &Hydraulics. Vol. 39 (2011), pp.113-115. In Chinese.
