Influence of the Outlet Aperture of Sensitive Chamber on the Stability of Fluidic Gyroscope

Abstract:

In this paper, influence of the outlet aperture of sensitive chamber on the stability of fluidic gyroscope has been studied. Using ANSYS-FLOTRAN CFD software, the finite element simulation was conducted by a series of procedures, such as two-dimensional model building of fluidic gyro, meshing, loads applying and equation solving, we calculated the airflow distribution in sensitive chamber of fluidic gyro with different outlet apertures. The results show that the airflow would decay and diffuse after it injects into the chamber through nozzle, the bigger the outlet aperture, the smaller the pressure in the outlet-side and the airflow velocity discharged from the outlet, and the more seriously the airflow decay and spread. An effective way to improve the stability and structural optimization of the fluidic gyro output has been studied in this paper.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 1096-1099
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.1096
• Online since: June 2012
• Authors: Bao Li Zhang, Lin Hua Piao, Quan Gang Yu, Chuan Zhi Mei, Xia Ding, Xing Wang
• Keywords: Finite Element, Flow Distribution, Fluidic Column, Sensitive Chamber

References

[1] Fuxue Zhang: Sensor Electronics (Defense Technology Press, Beijing 1991). (In Chinese).

[2] Linhua piao, Wei Zhang, Yu Lin, Fuxue Zhang: Electronic Components and Materials Vol. 21(7), (2002), p.8. (In Chinese).

[3] Yingxia Jin, Yonghong Zheng, Langfei Liu: Electronic Components and Materials Vol. 26(8), (2007), p.31. (In Chinese).

[4] Linhua piao, Bin Zhang, Jinduo Zhang, Fuxue Zhang: Piezoelectrics & Acoustooptics Vol. 27(3), (2005), p.309. (In Chinese).

[5] Quangang Yu, Linhua Piao, Xing Wang. Journal of Beijing Information Science & Technology University Vol.4 (2011), p.65. (In Chinese).
