The Applied Research of Four Polynomial Acceleration and Deceleration Control Method in Multi-Axis DSP Motion Controller

Abstract:

In traditional NC systems, the linear, index and S curve acceleration and deceleration control methods exist lots of problems that jerk is discontinuous or algorithm is too complex, seeking a more superior acceleration and deceleration control method to make up these shortages is needed. In this paper, the Four polynomial acceleration and deceleration control method is researched further, some contrast experiments have been done on NC terrace which is based on 32 bit floating point multi-axis DSP motion controller, and the superiority of this method and the practicability in NC field are analysed by processing two hemispheres with H600 CNC engraving and milling machine.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 567-572
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.567
• Online since: June 2012
• Authors: Jing Zhang, Wei Qiang Gao, Ze Hua Hu, Xiu Wen Huang, Jun Hua Song
• Keywords: Four Polynomial Acceleration and Deceleration, Motion Control, Numerical Control (NC), S Curve Acceleration and Deceleration

References

[1] Liangyuan Xu, Guisheng Gui and Dandan Peng: CAD/CAM and manufacture information,Vol.9 (2005), pp.66-67.(In Chinese).

[2] Chuan Shi, Tong Zhao etc: Chinese mechanical engineering,Vol.18(2007)No.12, pp.1421-1425.(In Chinese).

[3] Xingui Guo Congxin Li: Machine tool and hydraulic pressure,Vol.5 (2002), pp.60-62.(In Chinese).

[4] BiTao Zhang, Weiqiang Gao etc: Machine tool and hydraulic pressure,Vol.37(2009)No.10, pp.27-29.(In Chinese).

[5] Chuan Xu, Yongzhang Wang and Yuan Liu: Modular Machine Tool & Automatic Manufacturing Technique,Vol.8(2009), pp.42-48.(In Chinese).

[6] Hongbin Leng: Study on some key technologies of High performance NC system. (Zhejiang University Publications, Zhejiang 2008.4).(In Chinese).
