Research on Nozzle Array Structure Fluidic Gyroscope Zero Temperature Compensation

Abstract:

The nozzle array structure fluidic gyroscope’s zero temperature compensation was researched. The fluidic gyroscope’s temperature characteristic was analyzed in the sensitive element and two zero temperature compensation methods were compared. Then, the software compensation method was used, which based on the Single chip microcomputer technology and realized temperature compensation for the gyroscope output signal. The results show that after the compensation, the gyroscope’s zero drift decreases from ≤1.3mV/°C to ≤0.1mV/°C and operating temperature range increases from normal temperature to -40°C~+60°C. Therefore, the fluidic gyroscope has the advantage of low zero drift and width operating temperature range after the zero temperature compensation, which provides the convenience for the production and application.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 631-634
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.631
• Online since: June 2012
• Authors: Xing Wang, Lin Hua Piao, Quan Gang Yu
• Keywords: Fluidic Gyroscope, Nozzle Array Structure, Sensitive Element, Zero Temperature Compensation

References

[1] Van Thanh Dau, Otake Tomonori, Thien Xuan Dinh, etal. Proceeding of IEEE Sensors Conference, pp.666-669, (2008).

[2] V.T. Dau, T.Otake, T.X. Dinh. Proceeding of Actuators and Microsystems Conference, pp.1170-1173, (2009).

[3] Xing Wang, Linhua Piao, Quangang Yu. Journal of Beijing Information Science & Technology University, vol.26, pp.49-52, (2011).(In Chinese)

[4] Hainan Cai, Zhaoying Zhou. Journal of Measurement Technique, vol.6, pp.13-16, (1998). (In Chinese)
