Design and Application of Time-Domain Transmission Moisture Content of Crude Oil Sensor

Abstract:

According to the theory basis of time domain transmission technology, designed a new type of transducer for crude oil moisture measurement. Introducted the measuring principle of time-domain transmission moisture content of crude oil sensor, and designed the signal producing circuit, the machine oscillation circuit, the mixer circuit and phase detector circuit of the sensor. Finally, got the linear relationship between the output voiltage of the transducer and the crude oil moisture rate by testing. The accuracy of measurement is 1% when the water content is 50-100% in the crude oil and it is 2% when the water content is 0~50%.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 928-932
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.928
• Online since: June 2012
• Authors: Chun Yu Xiong
• Keywords: Mixer, Moisture Content of Crude Oil Sensor, Phase Detector, Signal Producing Circuit, Time Domain Transmission Technology

References

[1] Linli Xu, Jianhua Wang, Feng Hua: Research and Development. Vol. 26(2007), p.34, In Chinese.

[2] Jidan Chen: Dielectric Physics (China Machine Press, Beijing 1982), In Chinese.

[3] Guangjie Fu, Chunyu Xiong: Control and Instruments in Chemical Industry. Vol. 36(2009), p.53, In Chinese.

[4] Jinqi Wang, Xifu Qiang, Yongkui Zhang: Journal of Scientific Instrument. Vol. 23(2002), p.74, In Chinese.

[5] Su wen Zhang, Zhaoxiong Lu. High-frequency electronic circuits (Higher Education Press, Beijing 1999), In Chinese.

[6] Persson M D, Bendz P, Flyhammar P: Vadose Zone Journal, Vol. 3(2004), p.1146

[7] Shi H, Cai J, Jepson W P: Transactions of the ASME, Vol. 123(2001), p.270
