Study on Influencing Factors on Reliability of Permanent Magnet Synchronous Motor System in Electric Vehicle

Abstract:

In this paper, based on the working environment and characteristics of PMSM system in EV, the influencing factors and their action mechanism on the weak links with high failure rate are analyzed, concluded from the failure modes of PMSM system in EV. Temperature, as the most influential factor, is emphatically studied, combined with the related test results. The action mechanism of temperature on some typical components (winding insulation, bearing, permanent magnet and IGBT) is studied in detail, laying a foundation for further reliability expectation and test. This indicates that PMSM reliability can be tested and enhanced from its working temperature.

• Periodical: Advanced Materials Research (Volume 544)
• Pages: 151-158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.544.151
• Online since: June 2012
• Authors: Kai Li Yang, Qiang Song
• Keywords: Electric Vehicle (EV), PMSM, Reliability, Temperature

References

[1] HU Wei, WEN Xuhui, LIU Jun. Reliability analysis of motor driving system in electric vehicles[C]// International Conference on Electrical Machines and Systerns Nagasaki, Japan, (2006).

[2] HUANG Hongjian, LIN Ruiguang, Reliability and failure mode analysis for Brushless dc motor, Journal of motor and control, 4(4)(2000)198-201.

[3] Jeremy C.G Wheeler, Effects of converter pulses on the electrical insulation in low and medium voltage motors [J], IEEE Electrical insulation Magazine, 2005, 21(2): 22-29.

DOI: 10.1109/mei.2005.1412216

[4] GJB/Z 299C-2006, Reliability Prediction Handbook for Electronic Equipment.

[5] WANG Aimeng, LI Heming, The influence of permanent magnet material and temperature on performance and torque ripple of built-in permanent magnet motor, Journal of north china electric power university. 35(3)(2008)24-32.

DOI: 10.1109/iemdc.2009.5075222

[6] TANG Renyuan, Modern Permanent Magnet Machines Theory and Design, China Machine Press, Beijing, 1997.

[7] XU Lingyun, ZHANG Jianzhogn, WAN Li, Bearing burning caused by motor shaft current and its preventing measures, Hebei electric power technology. 22(3)(2003)17-18.

[8] Mechanical Design Hand Book, Machine Press, 2010.

[9] DU Mingxing, WEI Kexin, The review of fault mechanism and its forecast methods of IGBT module, World sci-tech r&d. 32 (6) (2010)741-745.
