Microstructure and Interfaces of Thin Film Capacitors on Base Metal Foils

Abstract:

The microstructure and interface quality of chemical solution deposited barium titanate thin films on Ni foil were studied. Cross-sectional transmission electron microscopy shows that a ~200 nm thick barium titanate film annealed in a controlled oxygen partial pressure consists of equiaxed grains with grain size range of 24-75 nm (~ 42 nm average). NiO was detected after re-oxidation by X-ray diffraction, but not by transmission electron microscopy, suggesting that the oxide is not a continuous barrier layer, but is spatially distributed in the films. Oxygen non-stoichiometry and the existence of C in barium titanate films were observed by electron energy loss spectrometry. In addition, it was found that there is a 5-8 nm thick Ni-Ba alloy developed at the interface between the barium titanate film and Ni foil.

• Periodical: Advanced Materials Research (Volumes 55-57)
• Pages: 917-920
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.55-57.917
• Online since: August 2008
• Authors: Tanawadee Dechakupt, G. Yang, Ian Reaney, Clive A. Randall, S. Trolier-McKinstry
• Keywords: Barium Titanate Thin Films, Electron Energy Loss Spectroscopy (EELS), Multilayer Ceramic Capacitor (MLCC), TEM
