Numerical Simulation of Flow Fields in Different Baffled Flocculation Reactors

Abstract:

The flow fields of the flocculators with different baffle which shape is vertical, perforated, arc and sine respectively were numerically simulated. The simulation parameters such as velocity, turbulent intensity, shaft power were compared in different types of baffled reactor. It shows that the calculated flow field matched the experiment results. Compared with the vertical baffles, the other three baffles such as perforated, arc and sine baffles, in varying degrees increased the average velocity and turbulence, and reduce energy consumption, in which the enhancement effects of sine baffles on flow field were especially prominent. In the sine baffled flocculator the average velocity and turbulent intensity was raised 2.6% and 3.8% respectively, and the shaft power was saved 5.78%. Reasonable structure of baffles can effectively resolve the problem of non-homogeneous mixture, intensify the flow field of flocculation reaction, improve flocculating effect, and reduce energy consumption.

• Periodical: Advanced Materials Research (Volumes 550-553)
• Pages: 3037-3040
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.550-553.3037
• Online since: July 2012
• Authors: Jiao Sun, Shao Hua Cui, Ze Zhan Sun, Yong Kang
• Keywords: Baffle, Flocculation, Flow Field, Reactor, Simulation

References

[1] M.H. Vakili, M. Nasr Esfahany. CFD analysis of turbulence in a baffled stirred tank, a three-compartment model. Chem. Eng. Sci.. 64(2009), pp.351-362

DOI: 10.1016/j.ces.2008.10.037

[2] T. Kumaresan, J.B. Joshi. Effect of impeller design on the flow pattern and mixing in stirred tanks. Chem. Eng. J.. 115(2006), p.173–193

DOI: 10.1016/j.cej.2005.10.002

[3] A. Gabriele, A.W. Nienow, M.J.H. Simmons. Use of angle resolved PIV to estimate local specific energy dissipation rates for up- and down-pumping pitched blade agitators in a stirred tank. Chem. Eng. Sci.. 64(2009), pp.126-143

DOI: 10.1016/j.ces.2008.09.018

[4] B.N. Murthy, J.B. Joshi. Assessment of Standard k−ε, RSM and LES Turbulence Models in a Baffled Stirred Vessel Agitated by Various Impeller Designs. Chem. Eng. Sci.. 63(2008), p.5468−5495

DOI: 10.1016/j.ces.2008.06.019

[5] D.Chapple, S.M. Kresta, A.Wall, et al. The effect of impeller and tank geometry on power number for a pitched blade turbine. Chem. Eng. Res. Des.. 80(2002), p.364−372

DOI: 10.1205/026387602317446407

[6] K. Yapici, B. Karasozen, M. Schäfer, et al.. Numerical investigation of the effect of the rushton type turbine design factors on agitated tank flow characteristic. Chem. Eng. Process.. 47(2008), p.1340−1349

DOI: 10.1016/j.cep.2007.05.002
