Modal Analysis of Vegetable Transplanter’s Mounting Headstock Based on ANSYS

Abstract:

Mounting headstock is an important part of the vegetable transplanting machine, its strength directly affects the machine's performance. The modal analysis of three types of headstocks while lifting and lowering implement were carried out with ANSYS finite element analysis software, the natural vibration characteristics including natural frequency, damping ratio and modal vibration mode of each particular mode without external interference were obtained, The comparison among the three structures was conducted and it may provide a theoretical basis for the structure design of the mounting headstock of vegetable transplanting machine .

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 550-553)

Pages:

3049-3053

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.550-553.3049

Citation:

Cite this paper

Online since:

July 2012

Authors:

Jun Ling Wang, Xin Xin Zhu, Zu Li Zhang, Yu Qiu Song

Keywords:

ANSYS, Modal Simulation, Mounting Headstock, Strength
