Structural and Fluid Flow Analysis of X-Style Blade Static Mixing Device

Abstract:

A static mixing device with X-style blade structure is designed, and internal structure is described in this paper. Fluid flows through sparse X-style blade static mixing unit, and dense X-style blade static mixing unit. The fluid is subjected impact, separation, circumfluence and merging, and the mixing effects are augmented, and the applicable scope of the mixing device can be widened, and mixing can be more efficient, and structural size can be reduced. The actual turbulent flow inside the mixing units of the static mixing device will be taken into account. The paper can provide foundations for structural improvement, parameters design and optimization of X-style blade static mixing device.

• Periodical: Advanced Materials Research (Volumes 550-553)
• Pages: 3072-3076
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.550-553.3072
• Online since: July 2012
• Authors: Qing Wu, Xue Jun Liu, Xiao Bei Wang, Yan Xiang Yang
• Keywords: Blade Structural Design, Fluid Flow Analysis, Static Mixing Device

References

[1] Maozhang Chen, Fundamentals of viscous Fluid Dynamics.HIGHER EDUCATION PRESS,BEIJING, 2002 (In Chinese).

[2] Zixiong Zhang, Zengnan Dong, Viscous Fluid Mechanics.TSINGHUA UNIVERSITY PRESS, BEIJING,1998(In Chinese).

[3] Zhaoshun Zhang, Guixiang Cui:Fluid Mechanics(The Second Edition).TSINGHUA UNIVERSITY PRESS, BEIJING,2006(In Chinese).

[4] Jianzhong Lin, Xiaodong Ruan, Bangguo Chen et al., Fluid Mechanics.TSINGHUA UNIVERSITY PRESS,BEIJING, 2005(In Chinese).

[5] Weixing Huang,Jianming Li,Zeyi Xiao, Engineering Fluid Mechanics(The Second Edition). CHEMICAL INDUSTRY PRESS,BEIJING,2009(In Chinese).

[6] Zuoru Chen, Engineering Fluid Mechanics(The Second Edition).HIGHER EDUCATION PRESS,BEIJING,2004(In Chinese).
