Studies on Self-Assembly of Methoxy Polyethylene Oxide Propyl Trimethoxysilane on Silicon Substrate

Abstract:

A novel hydrophilic and self-assemble functional methoxy polyethylene oxide propyl trimethoxysilane was synthesized by hydrosilylation reaction using methoxy polyethylene oxide monoallyl ether and trimethoxysilane. The self-assembled layer of methoxy polyethylene oxide propyl trimethoxysilane was prepared by immersing hydroxylate silicon substrate in silane solution. The structure, morphology and hydrophilicity of self-assembled layer were characterized by means of X-ray photoelectron spectroscopy (XPS), atomic force microscopy (AFM), and water contact angle method. The results show that methoxy polyethylene oxide propyl trimethoxysilane can self-assemble on the surface of hydroxylate silicon substrate. At concentration of 0.80 g/100 mL and the self-assembling time of 60 minutes, the self-assembled layer of methoxy polyethylene oxide propyl trimethoxysilane of average molecular weight of 682 shows a brush-like structure with each brush column size of 10~15 nm in diameter and 5~8 nm in height. The correspondence of the columns height with the average length of the silane molecules suggests that the layer obtained is monolayer and the brush columns are constituted by extended PEO molecular chain units in the silane. The distribution of columns is uniform and the root-mean-square（RMS） roughness of self-assembled monolayer is 0.98 nm. Water contact angle of the monolayer is 7.4°. A super-hydrophilic surface is obtained.

• Periodical: Advanced Materials Research (Volumes 557-559)
• Pages: 1916-1920
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.557-559.1916
• Online since: July 2012
• Authors: Wen Shi Ma, Fang Yang, Bang Jun Deng, Hai Yan Sun, Xiao Dan Lin
• Keywords: Brush-Like Structure, Hydrophilic Silane, Root-Mean-Square Roughness, Self-Assembly, Water Contact Angle

References

[1] Hoffmann C, Tovar G E. Mixed self-assembled monolayers (SAMs) consisting of methoxy-tri (ethylene glycol)-terminated and alkyl-terminated dimethylchlorosilanes control the non-specific adsorption of proteins at oxidic surfaces [J]. Journal of Colloid and Interface Science, 2006, 295(2): 427-435.

DOI: 10.1016/j.jcis.2005.10.005

[2] Anfeng Wang, Haiying Tang, Ting Cao, Steven O Salley, K Y Simon Ng. In vitro stability study of organosilane self-assemble monolayers and multilayers[J]. Journal of Colloid and Interface Science, 2005, 291(2): 438-447.

DOI: 10.1016/j.jcis.2005.05.008

[3] Ivan U Vakarelski, Cathy E McNamee, Ko Higashitani. Deposition of silica nanoparticles on a gold surface via a self-assembled monolayer of (3-mercaptopropyl)trimethoxysilane [J]. Colloids and Surfaces A: Physicochem Eng Aspects, 2007, 295(3): 16-20.

DOI: 10.1016/j.colsurfa.2006.08.021

[4] Linda A Chrisey, Gil U Lee, C Elizabeth O'Ferrall. Covalent attachment of synthetic DNA to self-assembled monolayer films [J]. Nucleic Acides Research, 1996, 24(15): 3031-3039.

DOI: 10.1093/nar/24.15.3031

[5] Duhua Wang, Yuhua Ni, Qun Huo, Dennis E Tallman. Self-assembled monolayer and multilayer thin films on aluminum 2024-T3 substrates and their corrosion resistance study [J]. Thin Solid Films, 2005, 471(1): 177-185.

DOI: 10.1016/j.tsf.2004.06.158

[6] Kihoon Jang, Kae Sato, Kazuma Mawatari, Tomohiro Konno, Kazuhiko Ishihara, Takehiko Kitamori. Surface modification by 2-methacryloyloxyethyl phosphorylcholine coupled to a photolabile linker for cell micropatterning [J]. Biomaterials, 2009, 30(7): 1413-1420.

DOI: 10.1016/j.biomaterials.2008.11.013

[7] Mary J Wirth, R W Peter Fairbank, Hafeez O Fatunmbi. Mixed self-assembled monolayers in chemical separations [J]. Science, 1997, 275(5296): 44-47.

DOI: 10.1126/science.275.5296.44

[8] Xiaoyan Song, Jin Zhai, Yilin Wang, Lei Jiang. Fabrication of superhydrophobic surfaces by self-assembly and their water-adhesion properties [J]. Journal of Physics Chemistry B, 2005, 109(9): 4048-4052.

DOI: 10.1021/jp045152l

[9] Atsushi Shimojima, Zheng Liu, Tetsu Ohsuna, Osamu Terasaki, Kazuyuki Kuroda. Self-assembly of designed oligomeric siloxanes with alkyl chains into silica-based hybrid mesostructures [J]. Journal of American Chemistry Society, 2005, 127(40): 14108-14116

DOI: 10.1021/ja0541736

[10] Koji Ishizu. Architecture of multi-component copolymer brushes: synthesis, solution properties and application for nanodevices [J]. Polymer, 2004, 36(10): 775-792.

DOI: 10.1295/polymj.36.775

[11] Tao Chen, Li Wang, Guohua Jiang, Jianjun Wang, Xue jie Wang, Junfeng Zhou, Wei Wang, Haoqi Gao. Large-size bamboo-shape nanotube from self-assembly of poly (ferrocenyldimethylsilane-b-dimethylsiloxane) block copolymer [J]. Polymer, 2005, 46(18): 7585-7589.

DOI: 10.1016/j.polymer.2005.06.017

[12] Fan H Y, Chen Z, Brinker C J, Clawson J, Alam T. Synthesis of organo-silane functionalized nanocrystal micelles and their self-assembly [J]. Journal of the American Chemical Society, 2005, 127(40): 13746-13747.

DOI: 10.1021/ja053795o

[13] Zhihao Yang, Jeffrey A Galloway, Hyuk Yu. Protein Interactions with Poly (ethylene glycol) Self-Assembled Monolayers on Glass Substrates: Diffusion and Adsorption [J]. Langumir, 1999, 15(24): 8405-8411.

DOI: 10.1021/la990260y
