Study on Hydraulic Characteristics of Flow around Rectangular and Semicircular Cross-Section Cylinder

Abstract:

In order to study the characteristics of flow around a side abutment, two model experiments of flow around rectangular and semicircular cross-section cylinder were conducted respectively, and an acoustic doppler velocimeter(ADV) was used to measure the instantaneous three-dimensional velocity components at vertical sections of two kinds of flow around the cylinder. Moreover, velocity vector, absolute velocity and turbulent kinetic energy were analyzed respectively at different vertical sections. The results reveal that: under the same conditions of upstream coming flow, the turbulence of the flow around a rectangular cross-section cylinder is strong ,and the maximum velocity are generated in the middle reaches of the cylinder near the side wall, The value of turbulent kinetic energy in the mainstream area is nearly zero. The flow around a semicircular cross-section cylinder is smooth, recirculation in the downstream is small, and the turbulence is weak.

• Periodical: Advanced Materials Research (Volumes 557-559)
• Pages: 2337-2342
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.557-559.2337
• Online since: July 2012
• Authors: Wei Dong Guo, Wei Sen Peng, Li Wang
• Keywords: 3-Dimensional, Absolute Velocity, ADV, Flow around a Cylinder, Turbulent Kinetic Energy, Velocity Vector

References

[1] SUN Hong-mei, GUO WEI-dong, ZHANG Lin, "Experimental study on the velocity profile around rectangular cross-section cylinder in rectangular open water channel," Yellow River, vol. 31, pp.114-117, April 2009 (in chinese).

[2] GUO Wei-dong, WEI Shuang, SUN Hong-mei, "Experimental study on turbulence intensity and Reynolds stress around rectangular cross-section cylinders in rectangular open channels," Advances in Science and Technology of Water Resources, vol 30, pp, 14-18, Feb 2010 (in chinese).

[3] GUO Wei-dong, Zhang Jiu-chang, LIN Hai-feng, "Experimental study on the velocity profile around semicircular cross-section cylinder in rectangular open water channel," Journal of Shenyang Agricultural University, vol 41, pp, 744-747, Dec 2009 (in chinese).

[4] GUO Wei-dong, GUO Wen-zhuo, ZHANG Li, "Experimental study of turbulent characteristics of flow around semicircular cross-section cylinder in rectangular open channel," Journal of Shenyang Agricultural University, vol 40, pp, 471-474, Oct 2009 (in chinese).

[5] Abdul Karim Barbhuiya, Subhasish Dey, "Turbulent flow measurement by the ADV in the vicinity of a rectangular cross-section cylinder placed at a channel sidewall," Flow Measurement and Instrumentation, vol 15, pp, 221-237, Feb 2004.

DOI: 10.1016/j.flowmeasinst.2004.02.002

[6] Abdul Karim Barbhuiya, Subhasish Dey, "Measurement of turbulent flow field at a vertical semicircular cylinder attached to the sidewall of a rectangular channel," Flow Measurement and Instrumentation, vol 15, pp, 87-96, Nov 2003.

DOI: 10.1016/j.flowmeasinst.2003.11.002
