Research on the Accuracy of Mask Projection Stereo-Lithography

Abstract:

In this research, sub-region curing and mask DPI modification are used to improve the accuracy of MPSL. Because the curing shrinkage at the discrete region does not cause the shrinkage of the entire resin surface, the accuracy of the RP work piece under sub-regional MPSL can be improved effectively. For the optical system error, the accuracy can be improved through the DPI (Dot per Inch) modification. The research results show that accuracy of work piece less than 12mm can be improved through DPI (Dot per Inch) modification. For the work piece above 16mm, the main method which improves the accuracy can adapt sub-region curing procedure. The combination methods of sub-regional exposure and exposure mask DPI modification can significantly improve the dimensional accuracy of parts, and the overall size of the error of parts can be controlled less than 1%.

• Periodical: Advanced Materials Research (Volume 566)
• Pages: 542-547
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.566.542
• Online since: September 2012
• Authors: Yi Qing Wang, Hua Ying Wu, Zhi Yang Jia, Wei Huang, Kun Sun, Bing Heng Lu
• Keywords: Accuracy, DPI Modification, MPSL, Sub-Regional Process

References

[1] Alfonso Maffezzoli, RAPID PROTOTYPING: AN OVERVIEW, [EB/OL]. Lecce, Italy: University of Lecce, 2008-1-7, http://www.prototipazione.unile.it/Download/unido_2000_stl.doc．

[2] Arnaud Bertsch, Paul Berghard, Christian Vogt, et al．Rapid prototyping of small size objects [J], Rapid Prototyping Journal, 2000, 6(4):259-266．

DOI: 10.1108/13552540010373362

[3] Cheng Yih-Lin, Li Meng-Long, Lin Jiang-Hong, at al. Development of Dynamic Mask Photolithography System [C], Proceedings of the 2005 IEEE International Conference on Mechatronics. Taipei, Taiwan. 2005, (7): 467-471.

DOI: 10.1109/icmech.2005.1529302

[4] EnvisionTec GmbH [Germany] : http://www.envisiontec.de/.

[5] Envision TEC news, http://www.envisiontec.com/index.php?id=108, 2009.

[6] You-Min Huang. Hsiang-Yao Lan, Path planning effect for the accuracy of rapid prototyping system, Int J Adv Manuf Technol, 2006, (30): 233–246.

DOI: 10.1007/s00170-005-0085-y

[7] P.F. Jacobs, Rapid Prototyping and Manufacturing Fundamentals of Stereolithography [M], ASME Press, New York, 1992.

[8] R. Delmdahl. R. Pätzel, Pulsed laser deposition - UV laser sources and applications, Source: Applied Physics A: Materials Science & Processing, Nov., 2008, 93(3): 611-615.

DOI: 10.1007/s00339-008-4716-7

[9] Yu Daoyin, Tan Hengying, Optical Engineering [M]．Machinery Industry Press．1999: 130-135.

[10] Yiqing Gao, Tingzheng Shen, Jinsong Chen, Ningning Luo, Xinmin Qi, Qi Jin, Research on high-quality projecting reduction lithography system based on digital mask technique [J], Optik，2005, (116): 303-310.

DOI: 10.1016/j.ijleo.2005.01.022

[11] ZEMAX Chinese manual, Optics Online [M / OL], 2002-11-10. www.photics.net.
