Analysis of Load Transfer Mechanism with Rock-Soil Anchoring Technology in Soil Tension-Type Prestressed Anchor for Civil Engineering

Abstract:

As an effective rock-soil anchoring technology, tension-type prestressed anchor is widely used in retaining foundation pits and slope for civil engineering because of its fewer perturbation, easier construction, more safety and more stability. The load transfer of anchorage section is the key to the civil engineering design and performance controls of the anchor. Several theoretic models for load transfer mechanism are compared and their insufficiencies are pointed out from the view point of civil engineering application.

• Periodical: Advanced Materials Research (Volume 568)
• Pages: 172-175
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.568.172
• Online since: September 2012
• Authors: Xiao Yong Wang, Jing Cao, Huai Xi Zuo
• Keywords: Anchorage, Load Transfer, Shear Stress, Soil Layer, Tension-Type Prestressed Anchor

References

[1] Liangkui Cheng, Jinglun Fan, Jun Han, Jianping Xu. Rock-soil Anchoring[M]. Beijing: Chinese architecture Industrial Press, 2003. 01: 1～10, 75～87.

[2] Technical code for building slope engineering(GB 50330-2002). Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Ministry of Construction people's republic of China. Beijing(2002).

[3] Specifications for bolt-shotcrete support(GB 50086-2001). Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Ministry of Construction people's republic of China. Beijing(2001).

[4] Technical Specification for Retaining and Protection of Building Foundation Excavations(JGJ120-99). Ministry of Construction people's republic of China. China Building Industry Press, Beijing(1999).

[5] Min Li, Zhongxin Jiang, Xiaolin Qin. The Stress Test Analysis about Inflation Rock (Soil) Cutting Slope in Nankun railway[J]. The Chinese Journal of Geological Hazard and Control, 1995, (special): 60～69.

[6] Liangkui Cheng. Some Mechanical Problems about Soil Anchor[A]. Rock-soil Anchoring Engineering Technology[M]. Beijing: The people's transportation university press, 1996: 1～6.

[7] Ping Yu, Yuan Yu. The experimental study about prestress anchor in landslide control[J]. The Chinese Journal of Geological Hazard and Control, 1996, (1): 59～63.

[8] Zhongxin Jiang. A gauss curve model on shear stress along anchoring section of anchoring rope of extensional force type[J]. Chinese Journal of Ceotechnical Engineering, 2001, 23(6): 696～699.

[9] Jiru Zhang, Baofu Tang. Hyperbolic function model to analyze load transfer mechanism on bolts[J]. hinese Journal of Ceotechnical Engineering, 2002, 24(2): 187～192.

[10] Chunan You. Mechanical analysis on wholly grouted anchor[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19(3): 339～341.

[11] Jinfeng Zou, Liang Li, Xiaoli Yang. Study on load transfer mechanism for span-type anchor based on the damage theory[J]. Journal of the China Railway Society, 2007, 29(6): 84～88.

[12] Jun Shen. The research about prestressed anchor reinforcement mechanism and the design calculation method[D]. University of Science and Technology of China Ph.D. Thesis, (2005).

[13] Qilong Wang. Discuss on the stress distribution mode in anchor section[J]. Subgrade Engineering, 2007, 5: 61～62.

[14] Shuancheng Gu, Hongqi Shao, Jiantao Zhong. Study on shearing stress distribution features of pre-stressed anchor anchored section[J]. Coal engineering, 2008, 11: 67～69.
