Analysis of the Strip Curvature in Tension Levelling with FEM

Abstract:

Confronting the problem that echnology parameters are difficult to set in the strip tension levelling process, in this paper takes the tension leveler as research object, using the ANSYS software to make dynamic simulation of strip tension levelling process, mainly analyse relationship between the intermesh and curvature, get result that curvature radius during the straightening process is much larger than bending roller radius, as well as the relationship between curvature and the intermesh under the specific structure condition, the research provides help for the optimization of the tension leveler equipment technology parameters.

• Periodical: Advanced Materials Research (Volume 572)
• Pages: 308-311
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.572.308
• Online since: October 2012
• Authors: Pei Jian Zhao, Cun Long Zhou, Wei Na Li, Qing Xue Huang, Yuan Hua Shuang
• Keywords: Curvature, Finite Element, Intermesh, Tension Levelling

References

[1] F. Cui . Straightening: principle and straightening machine, Metallurgical Industry Press (2007), p.378 (In Chinese).

[2] J.X. Zou: Rolling machine, Metallurgical Industry Press (2000), p.390 (In Chinese).

[3] T.H. Liu, Q.D. Zhang, J.R. Zhu: China steel annual conference (2005), p.550 (In Chinese).

[4] P. Wang, Y.C. Ren: Sichuan metallurgy (2005), p.19 (In Chinese).

[5] S.Z. Li, M. Chen, J. Yan: Second International Conference about advanced structural steel (2007), p.1062 (In Chinese).

[6] Anthony Parrico: AISTech 2008 Proceedings, Vol. Ⅱ (2008), p.763.

[7] J.C. Zhang, B.J. Dou: Non-ferrous metal processing (2003), p.36 (In Chinese).
