Development of a Micro Photoluminescence Measurement System for the Spectrum Inspection of Gallium Arsenide/Gallium Arsenide Phosphide (GaAs/GaAs_1-X P_x)

Abstract:

This article mainly focuses on the spectrum measurement of the LED semi-conductor material Gallium Arsenide/Gallium Arsenide Phosphide (GaAs/GaAs1-x Px), using Photoluminescence (PL) method, by integrating the optical path design, the mechanism design, the motion control, the image processing, and the positioning technology to accomplish the development of automatic measurement system. The innovative method of micro-photoluminescence (µ-PL) is proposed in the optical path design. A microscope objective was adopted to focus the laser light to a tiny area and by enhancing the strength of laser light unit to increase the sensitivity of the luminescence. In the past, the examination of PL was used to do the image positioning and to collect the luminescence manually in two different platforms. The developed system integrates these two light path systems, PL and image positioning, as one machine. As a result, the image positioning and luminescence measurement can be done in one machine simultaneously, to save manpower and to avoid the manual positioning error.

• Periodical: Advanced Materials Research (Volume 579)
• Pages: 464-472
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.579.464
• Online since: October 2012
• Authors: Mu Chiau Xie, Fang Jung Shiou, Geo Ry Tang, Shui Fa Chuang
• Keywords: GaAs, GaAs_1-x P_x, Micro-Photoluminescence (µ-PL), Photoluminescence (PL)

References

[1] Saime S. Cetin, Baris Kinaci, Tarik Asar, Ilknur Kars, Mustafa K. Ozturk, Tofig S. Mammadov, Suleyman Ozcelik, Effect of different P/As ratio on the optical and structural properties of GaAs1-xPx/GaAs, Surface and Interface Analysis, John Wiley & Sons Ltd, Chichester, (2010).

DOI: 10.1002/sia.3265

[2] Timothy H. Gfroerer, in Encyclopedia of Analytical Chemistry edited by R.A. Meyers, Photoluminescence in Analysis of Surfaces and Interfaces, John Wiley & Sons Ltd, Chichester, (2000) 9209-9213.

[3] Akasaki, H. Amano, M. Kito, K. Hiramatsu, Photoluminescence of Mg-doped p-type GaN and electroluminescence of GaN p-n junction LED, , Journal of Luminescence, (1991) 666-670.

DOI: 10.1016/0022-2313(91)90215-h

[4] X. H. Zhang, S. J. Chua, and W. J. Fan, Band offsets at GaInP/AlGaInP (001) heterostructures lattice matched to GaAs, , Applied Physics Letters, Vol. 73, (1998)1098-1100.

DOI: 10.1063/1.122096

[5] V. Swaminathan, A. T. Macrander, Materials Aspects of GaAs and InP based Structures, Prentice Hall, Englewood Cliffs, N.J., (1991).
