Comparative Research on Different Solutions of a High-Performance Thin-Film Polarizing Beam Splitter

Abstract:

In the process of fabricating an ultra-high precision thin-film polarizing beam splitter (PBS), which is the key element in a new kind of Y-shaped cavity dual-frequency laser, low production yield is a serious problem. Based on the robust design method by controlling sensitivity of optical films to production errors, response characteristics to production errors of different kinds of PBSs are comparatively studied. By experimental study of robust design, essential determinant of sensitivity of PBSs to production errors is found to be the physical requirement that the propagation angle should be larger than the critical angle of total reflection of the interface between the substrate and outer space. By fulfilling the physical requirement, optimum incidence angle has been found by repeated robust design on different incidence angles, and a high-performance thin-film PBS with low sensitivity to production errors has been designed. The coating structure of the obtained PBS is simple and it is easy to be batch manufactured, which will make a positive impact on fabrication, engineering and application of the new Y-shaped cavity dual-frequency laser.

• Periodical: Advanced Materials Research (Volume 580)
• Pages: 134-140
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.580.134
• Online since: October 2012
• Authors: Kai Yong Yang, Hong Chang Zhao, Yun Feng Jia, Su Yong Wu
• Keywords: Comparative Experiment, Robust Design, Thin Film, Thin-Film Polarizing Beam Splitter

References

[1] J. A. Dobrowolski and A. Waldorf: Appl. Opt. Vol. 20(1981), p.111.

[2] Li Li and J. A. Dobrowolski: Appl. Opt. Vol. 39(2000), p.2754.

[3] Long Xingwu, Xiao Guangzong and Zhang Bin: Acta Optica Sinica. Vol. 30(2010), p.3227.

DOI: 10.3788/aos20103011.3227

[4] Xiao Guangzong, Long Xingwu, Zhang Bin, Lu Guangfeng and Zhao Hongchang: Chinese J. Lasers Vol. 38(2011), p.1.

[5] Kaiyong Yang, Xingwu Long, Yun Huang and Suyong Wu: Optics Communications, Vol. 284(2011), p.4650.

[6] Wu Suyong, Long Xingwu, Huang Yun and Yang Kaiyong: High Power Laser and Particle Beams, Vol. 23(2011), p.1471.

[7] Huang Yun, Wu Suyong and Yang Kaiyong: Acta Optica Sinica. Vol. 31 (2011), p.1.

[8] Sh. Furman and A.V. Tikhonravov: Basics of Optics of Multilayer Systems(Editions Frontieres, France 1992).

[9] Wu Suyong, Long Xingwu, Huang Yun and Yang Kaiyong: High Power Laser and Particle Beams, Vol. 22(2010), p.83.

[10] Wu Suyong, Long Xingwu and Yang Kaiyong: Optoelectronics Letters Vol. 5( 2009), p.359.
