Design of Plane Curvilinear Welding Manipulator Control System Based on Motion Controller

Abstract:

The 3-D welding manipulator use the hardware of motion controller、IPC 、 stepping motor system and so on, motion control card was used to control three stepping motor, the curved beam design a append structural with“ ”shape to avoid splash in the welding process. In software development, use windows multithread technology to make sure the gesture demand of welding gun perpendicular to welder all the time. Practice has proved, the manipulator can interpolate welding curve and realize accuracy controlling of welding-torch position and gesture in the whole welding process.

• Periodical: Advanced Materials Research (Volume 580)
• Pages: 122-125
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.580.122
• Online since: October 2012
• Authors: Ru Xiong Li, Song Hua Jiao, Yan Wu
• Keywords: Manipulator, Motion Control Card, Plane Curvilinear, Weld

References

[1] Wu Lin, Chen Shanben. Intelligentized welding technology [M]. Bei jing: National efence industry press, (2000).

[2] Mao Pengjun, Lu Peitao, Huang Shisheng, etc. Review and foresight on technology development of welding robot. Welding. 2001, 45(8): 6-10.

[3] Yu Daji. Industrial robot application engineering [M]. Bei jing: Metallurgical industry press, (1999).

[4] Liu Jinhan. A research applied technologies of multirobots in a cab welding producion line. Robot. 2002, 24(1): 20-25.

[5] Xu Yuanchang. Industrial robot [M]. Bei jing: China light industry press, (1999).
