Study on Electrical Ignition Characteristics of HAN-Based Liquid Propellant Spray

Abstract:

In order to study the electrical ignition method of liquid propellant spray, two experimental devices of liquid propellant spray and alternating current (AC) pulse discharge were designed. By using of high speed digital camera system, the test on electrical ignition of HAN-based liquid propellant LP1846 spray were carried out under different injection pressures. The results show that under 50W AC pulse discharge conditions, LP1846 droplet cluster, with the mean diameter in the range of 20~40μm, can be ignited reliably. Based on above experiments, a simplified model of ignition delay time of LP1846 single droplet was set up, the calculation value is well matched with the experimental data.

• Periodical: Advanced Materials Research (Volumes 588-589)
• Pages: 268-272
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.588-589.268
• Online since: November 2012
• Authors: Yong Gang Yu, Chun Yi Lu, Na Zhao, Xin Lu
• Keywords: Electrical Ignition, Liquid Propellant, Spray, Transient Measurement

References

[1] Hurbert E, Applenhite J. Nontoxic Orbital Maneuvering and Reaction Control Systems for Reusable Spacecraft[J]. Journal of Propulsion and Power, 1998, 14(5): 676～687.

DOI: 10.2514/2.5330

[2] Meinhardt D S. Development and Testing of New, HAN-Based Monopropellants in Small Rocket Thrusers[R]. AIAA-1998-4006, (1998).

DOI: 10.2514/6.1998-4006

[3] Anflo K. Development and Testing of AND-Based Monopropellants in Small Rocket Engines[R]. AIAA-2000-3162, (2000).

DOI: 10.2514/6.2000-3162

[4] Yetter R A, Yang V, et al. Development of Meso and Micro Scale Liquid Propellant Thrusters[R]. AIAA-2003-0676, (2003).

[5] Chang Y P, Josten J K, Kuo K K. Combustion Characteristics Energetic HAN/Methanol-Based Monopropellant[C]. 38th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit. Indianapolis, Indiana, P. 205～219, (2002).

DOI: 10.2514/6.2002-4032

[6] DeSpirito J, Knapton J D. Electrical ignition of Han-based liquid propellants[R]. ADA195094, (1988).

[7] Klingenberg G, Frieske H J. Electrical Ignition of Han-based liquid propellants[R]. ADA223272, (1990).

DOI: 10.21236/ada223272

[8] Klingenberg G, Rockstroh H, Knapton J D, et al. Investigation of liquid gun propellants: electrical ignition of LGP 1846 [J]. Journal of Propellants, Explosives, Pyrotechnics. 1990, 15(3): 103-114.

DOI: 10.1002/prep.19900150308

[9] Rockstroh H, Frieske H J, Klingenberg G. Electrical Ignition of Han-based liquid propellants[R]. ADA226314, (1990).

DOI: 10.21236/ada223272

[10] LI Bao-ming, GUAN Han-zhang. Experimental study on electrical ignition parameters of HAN-based liquid propellant[J]. Journal of Ballistics, 1995, 7(4): 36-41.

[11] Zhang Xuzhu, Xiao Zhongliang. Liquid Propellant. Beijing: Chinese Science and Technology Press, 1993. (in Chinese).
