The Green Design of Bracket of Scraper Part of Coal Mine Underground Horizontal Extension Transfer Machine

Abstract:

Recently, transporting coal in the coal mine is poor efficiency and too costly. Coal mine underground horizontal extension transfer machine is used to transport coal faster and better. To resolve the problem how to connect the scraper conveyer with tramcar in this system, the design of the bracket has been brought up. The bracket of scraper part is the main bearing of coal mine underground horizontal extension transfer machine, and all the scraper conveyer must be fixed in the bracket. In addition, the design of the bracket of scraper part not only considers the rationality in the structure, but also considers the effect of the environment. The system works in extreme circumstances, but the green design can resolve it. It can effectively combine the choice of material, the structure of the bracket, the methods of technology with exterior styling, reflecting the human, machine of harmony with the working environment.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 44-47
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.44
• Online since: November 2012
• Authors: Ping Huai Mao, Li Ding, Jing Xi Li
• Keywords: Bracket, Green Design, Scraper Part, Structure

References

[1] P.H. Mao and C.J. Wang: Mining & Processing Equipment, Vol. 33 (2005) No.3, P.34 (In Chinese).

[2] G.F. Liu: Green Design and Manufacture, Vol. 1(2007) No.05 (In Chinese)

[3] C.Y. Wu, J.G. Yuan and H.J. Hong: Hydraulic Coal Mining & Pipeline Transportation, Vol. 1(2008) No.02, P. 39(In Chinese)

[4] P.H. Mao: Coal Mine Machinery, Vol. 01 (2005) No.11, P.31 (In Chinese)

[5] A.J. Zhu: Mining Machine and Convey, Vol.01 (2008) No.23, P.25 (In Chinese)

[6] G.C. Wu: Nonferrous Metals (Mining Section), Vol. 1(1981) No.02 (In Chinese)

[7] P.H. Mao, Q. Ye: Coal Science and Technology, Vol. 35 (2007) No.8, P.18 (In Chinese).

[8] H.W. Liu: Mechanics of Materials, Vol.01 (2003) No.38, P.48 (In Chinese)
