One Effective Solution of Hot Swap Application

Abstract:

In the paper, mainly introduce one new solution for power and signals hot swap function. The solution is not need special connector, as slotting jack and special insert way, only use the normal connector, such as simple board to board connector. Even board to wire connector, could mount the slave on the host or place slave horizontally with host, so the inserting or plugging way is flexible. This need design one protect circuit for this effective solution of Hot Swap Application.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 441-444
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.441
• Online since: November 2012
• Authors: Zhan Jun Zhang
• Keywords: Hot Swap, Robust Solution, Signal Connect

References

[1] Yi Chen, David Ki-Wai Cheng, Yim-Shu Lee, "A Hot-Swap Solution for Paralleled Power Modules by Using Current-Sharing Interface Circuits" IEEE TRANSACTIONS ON POWER ELECTRONICS, VOL. 21, NO. 6, NOV. 2006, PP 1565-1571

DOI: 10.1109/pesc.2005.1581681

[2] Rakosi, Z.E.; Hiromoto, M.; Ochi, H.; Nakamura, Y.; Field Programmable Logic and Applications, 2009. FPL 2009. PP. 578-581

[3] M. Abramovici, J. M. Emmert, and C. E. Stroud, "Roving STARs: An integrated approach to on-line testing, diagnosis, and fault tolerance for fpgas," in Proc. NASA/DoD Workshop on Evolvable Hardware, 2001, p.73–92.

DOI: 10.1109/eh.2001.937949

[4] Jun Guo, Jun Zhang, Pei Li, "The circuit design for hot swap based on TPS2301", Electronic Component & Device Applications, Vol.12 No.6 2010. PP 17-19 (In Chinese)
