Quantitative Analysis of Several Influencing Factors on TBM Advance Speed

Abstract:

Aiming at the problem of a difference between the TBM advance speed estimated by the NTNU and CSM model, and the actual advance speed, a quantitative analysis is carried out in the paper. Combining the experimental results of the uniaxial compressive test with the rock mechanics experiment system TAW-2000 and MTS815, the paper quantitatively characterizes the main parameters including the rock compressive strength, elastic modulus, abrasiveness, and the thrust force of cutterhead, corresponding to TBM advance speed by using the method of quantitative analysis of multi-factors. Moreover, the relationship between the TBM advance speed and the parameters was established. It is indicated that higher rock strength, abrasion and a smaller thrust force of cutterhead are reasons resulting in a lower TBM advance speed.

• Periodical: Advanced Materials Research (Volumes 594-597)
• Pages: 1318-1323
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.594-597.1318
• Online since: November 2012
• Authors: Chao Li, Joachim Tiedemann, Hong Wei Zhou
• Keywords: Abrasiveness, Advance Speed of TBM, CSM, NTNU, Rock Compressive Strength, Thrust Force of Cutterhead

References

[1] Ozdemir L., Miller R.J., Wang F.D., " Mechanical tunnel boring prediction and meachine design"[J]. NSF APR73-07776-A03, Colorado School of Mines, GoldenColorado,USA (1978).

[2] Graham P. C. Rock Exploration for Machine Manufacturers, in Exploration for Rock Engineering [J]. Bieniawski Z. T. (ed.), Proceedings of the Symposium, Johannesburg, Balkema, Vol. 1 (1976), pp.173-180.

[3] Farmer I. W. and Glossop N. H. Mechanics of Disc Cutter Penetration[J]. Tunnels and Tunnelling International (1980), 12(6):22-25.

[4] Barton N. TBM performance estimation in rock using QTBM[J]. Tunnels andTunnelling International (1999), (9):30-34.

[5] Gong Qiuming. Development of a rockmass characteristics model for TBM penetration rate prediction[D]. Doctoral dissertation, Nanyang TechnologicalUniversity,Singapore (2006).

[6] Bruland, A.. Hard Rock Tunnel Boring – Drillability Statistics of Drillability Test Results. Doctoral Theses, University of Trondheim (1998).

[7] Rostami J.. Development of a force estimation model for rock fragmentation with disc cutters through theoretical modeling and physical measurement of crushed zone pressure[D]. Doctoral dissertation, Dept. of Mining Engineering, Colorado School of Mines, Golden, Colorado, USA(1997), P.382.

[8] DAUB, Deutscher Ausschuss fuer unterirdisches Bauen e.V.(2010):Empfelung zur Auswahl von Tunnelvortriebsmaschinen.

[9] Girmscheid G. (2008): Baubetrieb und Bauverfahren im Tunnelbau. 3.Auflage, Ernst und Sohn, Berlin.

DOI: 10.1002/9783433600191

[10] Centre D'Etudes ET Recherches de Charbonnages de France (1986): The Cerchar- Abrasiveness Index.–12S.,Verneuil(Eigenverlag).
