Finite Element Analysis of 2450 Type Close-Top Mill Housing

Abstract:

Aimed at the maximum stress and distortion, the three-dimensional model of 2450 type close-top mill housing was simulated by finite element analysis, with the help of FEM software (ANSYS). The positions of dangerous sections and the maximum stress was shown in stress contour. The displacement and maximal displacement of various points was obtained in the deformation contour. The results show that different structural parameters was used for the key parts, and the influence of parameters to stress and deformations can be obtained, which can provide reference for the design of the related mill housing.

• Periodical: Advanced Materials Research (Volume 601)
• Pages: 173-176
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.601.173
• Online since: December 2012
• Authors: Xi Wang, Chang Liang Xu
• Keywords: Deformation, Finite Element Method (FEM), Mill Stand Housing, Stress
